Outdoor Advertising LED Display /Image Display /Video IP65

Product Specifications

Prod Model:	P5
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lifespan:	100,000 Hours
Warranty:	2 Years
Factory Price:	Available
Display Type:	LED Video Display
Tube Chip Color:	Full Color
IP Rating:	IP65
Pixel Configuration:	1R, 1G, 1B
Certification:	CCC
Application:	Advertising
Scanning Mode:	1/8 Scan
Pixel Pitch:	5
Display Function:	Video/Image/Text Display
Pixel Density:	40000 Dots/ M2
Average Power Consumption:	830W/Each

Product Description

 Outdoor Advertising LED Display /image display /video IP65

specification:

Part Number	HERO-OD
Resolution	32(H)×32(V)
Pixel Pitch	5mm
LED Configuration	1R1G1B  SMD3528
Pixel Density	40000 pixels/ m2
Module Size	160*160mm
Driving IC	MBI5024
Driving Method	Static Scan, Constant Current
Cabinet Weight	210kg/each
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	±0.25
Optical Ratings
Brightness	3500~4500cd/ m2
View Angle	140°/140°
Gray Scale	16bits
Display COLOR	281 trillion
Brightness Adjustment	0~100%
Power Supply
Operation Power	50~60Hz
Max. Power Consumption	2000W/ m2
Average Power Consumption	800W/ m2
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60-85HZ
Screen Refresh Frequency	300~1000Hz
Gamma Correction	-5.0~+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode	1024x768,1280x1024,1600x1200,1920x1280
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°~+60°
Operating Humidity	10~95% RH
Operating Life	100,000hours
MTBF	10000hours
Protection Level	~
Out of Control Rate	<0.02%

Description:
1.Both front and back opening,maintain coveniently.
aluminum alloy structure with 5mm tempered glass,opening angle convenient for installation and maintenance.
2.Waterproof structure IP65 front and IP54 rear.
3.High brightness, and high definition.
The brightness can up to 4500 cd/m2.
4.Appearance structure standard.
standardization of products,a variety of application only need to replace the module.
5.Movable
screen rely on the base where equipped with four wheels and positioning wheels pin,right angle with brake,fast moving,quick stop.
rotatable wheels and adjustable foot,greatly improving the stability.
6.Fast connections,time-saving patent.
removable rings on top,easily carry and packing.
design of rings for lifting,saving cost of manpower handling and improve security.
7.Cooling control principle/internal power distribution system.


Applications:
Widely used  shopping malls, commercial streets,municipal public buildings, landmarks and other advertising.


Packing and transportation

Professional packaging:wooden box or flight case.
The way of Packing can prevent the collision of LED screen effectively in the process of transportation, such as falling damage,etc.
Faultlessly solve your worries in the transportation.



About Hero

7-year's experience in LED screen, our factory has the ability of processing, researching and developing led display to ensure the prolificacy.A strict quality control process to make sure the led display screens is with high quality.

After-sale service
1) Warranty:
Free to solve the quality problems to ensure that equipment normal operation in the warranty period . At any time, we bear all the responsibility, when the problem is from the product itself.
2) Free maintenance:
Free warranty in the warranty period.
Only charge the cost of raw materials, provide spare parts and maintenance services for the lowest price after the warranty period.
3)quick response:
Response within 2 hours, non-artificial, general fault solution within 24 hours, and acceptable failure resolved within 48 hours.
4) Free support:
Through telephone or network to provide service support in real time, or with the help of a network for remote debugging support (software), to solve the problem.
