P8.928 Outdoor Full Color LED Display with High Brightness
Product Specifications
| Prod Model: |
P8.928-outdoor |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LED Encapsulation: |
SMD3535 |
| Module Size: |
250X250mm |
| Cabinet Size: |
500X500mm |
| Cabinet Resolution: |
56X56dots |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
300W / m² |
| Display Type: |
LED Video Display |
| Certification: |
RoHS |
| Pixel Pitch: |
8.928mm |
| Pixel Density: |
12546dots/Sq.M |
| Scanning Mode: |
1/7 |
| Application: |
Advertising,Stage Performance,Rental |
Product Description
P8.928 Outdoor Full Color LED Display with die-casting aluminum cabinet 500x500mm or 500x1000mm for outdoor rental or permanent install, 1.SMD3535 led encapsulation confirm high brightness and wide view angle
2.Good waterproof IP65, long life span>100000Hours
3.Bigge pixe pitch, long view distance,can be seen from 100M away
4.With Die-casting aluminum cabinet, light weight and stability,can stand singly
5.With fast locks and aviation plugs for quickly connection, convenient to combine and dismantle
6.Only with one power supply,low power consumption, no fans low noise created,
7.Widely used for stage, concert, show, banquet, wedding, rental display, outdoor advertising
| P8.928 Outdoor full Color LED Screen Specification |
| Pixel pitch | 8.928mm |
| Pixel Configuration | 1R1G1B |
| LED component | SMD3535 black |
| Size of module | 250mm x 250mm |
| Resolution of module | 28x28 |
| Size of cabinet | 500mm x 500mm x 75mm |
| Resolution of cabinet | 56x56 |
| Material of Cabinet | Die-casting Aluminum |
| Weight of Cabinet | <8KGS |
| Brightness | >6000cd/m² |
| Density | 12546dots/m² |
| Best viewing angle | 140 /140 |
| Best viewing distance | 8-100M |
| Maximum power consumption | <800W/m² |
| Average power consumption | <300W/² |
| Driving method | 1/5 scan |
| Control method | Synchronization |
| Gray scale | 65536 |
| Colors | 256*256*256 |
| Color temperature | 3200-9300k |
| Uniformity | 97% |
| Working voltage | AC220V/110V±10% |
| Working temperature | -20ºC~+50ºC±10% |
| Working humidity | 10% ~ 90% |
| MTBF | 10,000 hours |
| Frame frequence | 50/60Hz |
| Refresh frequence | >1800Hz |
| IP grade | IP65 |
| Life Span | 100,000 hours |
| Data transafer method | RJ45 |
| Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication
Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
| Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
PRT OPTOELECTRONIC Co., Ltd is located in Bao'an District of Shenzhen city, specializing in R& D, manufacturing Full Color LED display for outdoor and indoor advertising with many different pixel pitches, and many different design, owned 5 new-automatic production lines and advanced test equipments to control quality ensure high quality. And got the international standard certificates of ISO9001-2000 and 14001, CE, CCC, FCC, RoHS, gurantee high quality!
Our main products include Outdoor LED display, Indoor LED display, Rental LED Display, Stage backbround LED screen, LED Curtain, Sport stadium perimeter LED screen, Mobile LED screen, LED display modules etc. Also supply LED professional stage lights based as customer's requests.
As the growing, we have more than 150 staffs, mostly with rich working experience in this area for many years, and several professional engineers for production and after sale service.
We got a strong team for exporting business, members with rich exporting experience over ten years, to introduce better solutions based on customers' requirements professionally, and guarantee the products to be shipped out in time and smoothly, so we can provide our clients high quality products with competitive prices and excellent service, and have obtained a good reputation from our customers.
Our company's operating philosophy, "Quality is everything, Service is the key to success ", because our purpose is to let business done easily and trustingly, to save customer's searching time and purchase cost, solve problem on customer's position, to let everything to be "PERFECT"(abbreviated to"PRT" )!
PRT is a developing company, need hard work of our staffs, also need your large positive support, let us do business and develop together, "sincere cooperation, mutual benefit and common development" is our principle.
Please send your e-mail to us and call us directly, we will answer you as soon as we can.
Business Type: Manufacturer/Factory
International Commercial Terms: FOB, CFR, CIF, EXW
Terms of Payment: LC, T/T, PayPal, Western Union, Money Gram
Average Lead Time: Peak season lead time: within 15 workdaysOff season lead time: within 15 workdays
Number of Foreign Trading Staff: 4~10 People
Export Year: 2011-02-20
Export Percentage: 71%~90%
Main Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Export Mode: Exportation via agency
Factory Address: A5-A708,West Song Bai Road,Shiyan Town Bao'an District
R&D Capacity: OEM, Own Brand(PRT)
No. of R&D Staff: 5-10 People
No. of Production Lines: 5
Annual Output Value: US$10 Million - US$50 Million
