PA Audio, PA Loudspeaker, Professional Loudspeaker PRO Audio (PL-15)
| Price: |
US $ 100-200/Piece |
| Trade Terms: |
FOB,EXW |
| Min Order: |
2/Piece |
| Pay Type: |
T/T |
Product Specifications
| Prod Model: |
Pro audio PL-15 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 15" Speaker: |
2 Way 15" Speaker |
| Application: |
Commercial |
| THD: |
<0.005% |
| Certification: |
CE |
Product Description
NOVA make line array speaker, pro audio, professional loudspeaker, amplifier, signal processor,flgithcase.
The PL sereis interates a selection of cost effective full range systems suitable for a wide variety of fixed or applications in small and medium sized environments where reduced cabinet dimensions and high output capability are essential.Specfication for PL-15:
Frequency response: 50Hz-18kHz
RMS power: 350W
Programe power: 700W
Norminal impedance: 8ohm
Sensitivity: 100/w/m
Max spl: 125dB
Component: 15" + 2" horn
Dispersion: 100H X 90V
|
Model number |
F8 |
F10 |
F12 |
F15 |
F-215 |
|
Frequency response |
65Hz-20KHz(-10dB) |
60Hz-20KHz(-10dB) |
50Hz-20KHz(-10dB) |
45Hz-20KHz(-10dB) |
40Hz-20KHz(-10dB) |
|
|
70Hz-19KHz(±3dB) |
65Hz-19KHz(±3dB) |
55Hz-19KHz(±3dB) |
50Hz-19KHz(±3dB) |
45Hz-19KHz(±3dB) |
|
RMS power |
200W |
250W |
300W |
400W |
700W |
|
Program power |
400W |
500W |
600W |
800W |
1400W |
|
Norminal Impedance |
8Ohm |
8Ohm |
8Ohm |
8Ohm |
4Ohm |
|
Sensitivity |
96dB/W/M |
97dB/W/M |
99dB/W/M |
101dB/W/M |
103dB/W/M |
|
Max SPL |
119dB |
121dB |
124dB |
127dB |
131dB |
|
Component |
1"+8" |
1"+10" |
1.4"+12" |
2"+15" |
2x15"+2" |
|
Coverage Angles |
80H°x50°V |
80H°x50°V |
80H°x50°V |
80H°x50°V |
80H°x50°V |
|
Dimenstion |
280x270x435mm |
335x315x500mm |
380x370x602mm |
452x442x692mm |
540x495x1070mm |
Nova specializes in manufacturing PRO audio which including line array, professional loudspeakers & KTV, power amplifiers, mixers consoles, signal processors including equalizers, limiters/compressors, exciters, crossovers, power sequence controllers etc. To meet different customer's market, we also add producion line for woofer speakers, subwoofer speakers and flightcase for sound equipmentand professional lights and LED monitor ect.
With experienced & strong R&D department and strictly quality control managment and Satisfactory market service system and reasonable price and good quality, Our price had got high reputation in many ares.
OEM/ODM also available.
Nova will offer what you want.
Please join in NOVA family!
