Product Specifications
| Prod Model: |
BCP |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Metal Cutting Machine |
Product Description
Plasam cutter machine
Features:
Unique structure: Gantry structure, double motor driver of Y axis. Light beam design, linear guide rail, high accuracy, stable transmission. Untouched plasma head, small cutting edge, no cutting residue. Water cooling system avoids the distortion of metal board. High cutting speed, high accuracy, low cost. Advanced numeral control system, stable performance. Software compatability: Ucancam, Type 3, Artcum, etc. Success ratio of arc striking can be over 99%. Application area: Metal sheets such as Iron sheets, Aluminum sheets, Galvanized sheets. Tianium Plates. Welded lathe bed of thick-wall profiled steel, more solid and stable.
Applicable Industries:
Ship Building, Construction Equipment, Transport Equipment, Aerospace Industry, Bridge Building, military industrial, wind power, Structural Steel, Boiler containers, Agriculture Machinery, Chassis electrical cabinets, Elevator manufacturers, Textile Machinery, Environmental protection equipment, ect.
|
Description |
BCP0609, BCP1325, BCP1530 |
|
Working Area(X*Y) |
600*900mm, 1300x2500mm, 1500*3000mm |
|
Cutting thickness |
0.1-15mm |
|
Max Moving Speed |
15000mm/min |
|
Cutting Speed |
0-6000mm/min |
|
Machine Structure |
Welded |
|
X Y Guide Rail |
Square Rail |
|
X Y Transmission |
Rack gears |
|
X\Y\Z Axis Driver |
Steper Motors |
|
Operating System |
DSP with USB Interface |
|
Working Dictate |
G Code |
|
Document Transmission Form |
USB Interface |
|
Working Form |
Untouched Arc Striking |
|
Working Voltage |
AC220V, 50Hz/60Hz (AC380V, 50Hz/60Hz) |
|
G. W. |
900KGS |
|
Packing Size |
7.1 CBM |
Jinan Bodor CNC Machine Co., Ltd., has been always devoting to the research and manufacture of the CNC products such as laser engraving machine, laser cutting machine, laser marking machine and so on. Today, Bodor CNC has developed to a large worldwide Manufacturing Group, and becomes an excellent leader of the world in this field.
Bodor CNC can supply DOT peen marking machines, Laser Marking Machines, CNC Router (Mechanical Engraving and Cutting Machines), Laser Engraving and Cutting Machines and many other industrial automation equipments. Meanwhile we can also supply industrial automation solutions according to your special needs.
Bodor CNC has earned ourselves a good reputation and ten thousands of faithful customers with our advanced technology, standardized producing management, stable products, and the best services. Through years of international marketing experience, we have established business relationships with the customers from North America, West Europe, South Asia, and Middle East, etc. Welcome to join the world of Bodor CNC, You can experience the world-class products and services together with our customers all over the world.
