Portable Type Hydraulic Teaching Set

1. Oveview
DLYY-X1 Portable type hydraulic training system, is design, research and develop according to experimental teaching outline of the national college "hydraulic transmission" for guidance, and combine with requirements of vocational training and professional further study to the fluid drive. This training device uses operating board of the open structure, all kinds of hydraulic components can be flexible install in operation board, connect with hydraulic pressure tube between components, the quick-change connector of hydraulic hose can make training experiment is fast and safe. Besides large whole set of components can be chose to upgrade! It has very strong expansibility and actual exercise, has the following features:

· Can meet the requirements of the school

· Meet the base and teaching training system of need of practical applications.

· Equipment structure is firm and has good stability

· Low noise operation

· Layout clear and intriguing design

2. Technical parameter
1). Input power: Single phase, three-wire, AC 380V, 50Hz /60Hz
2). Dimension of training box: 470*560*260mm
3). System flow: Max 10L/min
4). Dimension of aluminum panel: 450× 480mm

Accomplish experiment contents:

1. Directional control circuit

A) Inverting circuit of hand shuttle valve

B) Magnetic shuttle exchange circuit

2. Pressure control circuit

A) Single grade pressure regulating circuit

B) Secondary level pressure regulating

C) The unloading circuit using the shuttle valve

D) The unloading circuit using the relief valve

H) Liquid control one-way valve pressure-protection

3. The flow speed circuit

A) Enter oil-way throttle speed regulation

B) Back oil-way throttle speed regulation

C) Side oil-way throttle speed regulation

D) Speed synchronous circuit of the speed regulation valve

4. Sequence action circuit use stroke switch control

5. One-way latch circuit use hydraulic control one-way valve

6. Locking circuit use O type manual shuttle valve

7. Differential control circuit

8. Relay control hydraulic basic circuit

9. The other circuit design by themselves
