Product Specifications
| Prod Model: |
DLFA-PCT |
| Markets: |
North America,South America,Southeast Asia,Africa,Mid East,Eastern Asia |
| Electrical Logic: |
NPN |
| Capacity: |
:Less Than 1kVA |
| Drive Motor: |
DC Gear Reducer Motor |
| PLC: |
Siemens or Othe Rbrand |
| Weight: |
27kg |
| Dimension: |
850×750×750(Mm) |
| Type: |
Teaching Model |
| Laser Model: |
Technicians Education Equipment |
Product Description
DLFA-PCT
Position Control Trainer
1. Overview
This training device can achieve plane position control in the movement, in the PLC control, can be realized plane rear wing position control, and through the pneumatic institutions to grab and put, through the DC reduction motor (high performance servo motor, step motor) to control precision instrument in the movement, this equipment is for research PLC system design special develop and design, complete the inspection, control, and implement of the three major module training. Let the students understand and master mechanical and electrical integration knowledge.
This training device is two dimension motion control model, and combine with sensors, PLC, pneumatic, electric motor control, and grab the workpiece by vacuum way.
2. Parameter
NO. Parameter
1Input power: AC220V± 10%(single-phase three-wire)
2Capacity: <1KVA
3Environment temperature: -10° C~40° C
4Relative humidity: ≤ 85%
5Weight: 27Kg
6Electrical logic: NPN
7Drive motor: DC gear reducer motor
8Drive type: Axle drive
9Z axle: With proximity switch and flow control switch
10Eventually actuators: Vacuum cups
11Controller: Mitisubishi or other brand
12Dimension: 850× 750× 750(mm)
Shandong Dolang Technology Equipment Co., Ltd. Was founded as a partner of Shandong university in 1998. Thanks for the customers, professional engineers and all our skilled workers, Dolang has been grown up to a professional and powerful global enterprise with 16 years dedicated experience on the didactic equipment. As a member of Worlddidac Association, our products are made under the requirement of ISO9001, ISO24001 and OHSMS28001.
We are professional on manufacturer electrical & electronic, PLC, fluid mechanical, hydraulic, pneumatic, process control, mechatronics, automation, CIM training and automobile training systems.
Besides the physical training system, Dolang provide solutions for customer such as system thinking, E-learning and so on.
Our products are involved in various education equipment industry fields. We serve in 100 universities and more than 300 vocational colleges in China. With self-operation export & import license, our products have being exported to France, Russia, Mongolia, Tunisia, Mexico, Brazil, Peru, Indonesia, Iraq, Cyprus, Vietnam, Kazakhstan etc.
