Product Specifications
| Prod Model: |
MY64 |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Grade: |
Professional |
| LCD Display: |
2000 Counts |
| Diode: |
2.7V |
| Display Mode: |
Digital |
| Power Source: |
AC and DC |
| Theory: |
Electronic Meter |
| Installation: |
Portable |
Product Description
Digital Multimeter MY64
Features of Digital Multimeter MY64
* Display: 2000 counts
* Transistor hFE: 0~1000
* Didoe: 2.7V
* Continuity Buzzer: <50Ω
* Data hold: yes
* APO: Auto Power Off
* LBD: Low Battery Display
Specifications of Digital Multimeter MY64
* DC Voltage
- Range: 200mV/2V/20V/200V; Accuracy: +/-(0.5%+3)
- Range: 1000V; Accuracy: +/-(0.8%+3)
* AC Voltage
- Range: 2V/20V/200V; Accuracy: +/-(0.8%+3)
- Range: 750V; Accuracy: +/-(1.2%+3)
* DC Current
- Range: 2mA/20mA/200mA; Accuracy:+/-(1.5%+1)
- Range: 10A; Accuracy: +/-(2.0%+5)
* AC Current
- Range: 2mA/20mA/200mA; Accuracy:+/-(1.8%+5)
- Range: 10A; Accuracy: +/-(3.0%+5)
* Resistance
- Range: 200Ω/2KΩ/20KΩ/200KΩ/2MΩ; Accuracy:+/-(0.8%+3)
- Range: 20MΩ; Accuracy: +/-(1.0%+5)
- Range: 200MΩ; Accuracy: +/-(6.0%+10)
* Capacitance
- Range: 2nF/20nF/200nF/2μF; Accuracy: +/-(4.0%+3)
- Range: 100μF; Accuracy: +/-(6.0%+10)
* Frequency
- Range: 20kHz; Accuracy: +/-(1.5%+5)
* Temperature(°C)
- Range: -20°C~1000°C; Accuracy: +/-(2%+2)
* Power supply: 1x9V 6F22 Battery
* Product size: 195mm x 95mm x 55mm /7.67" x 3.74" x 2.16"
* Product weight: 366g/0.8lb
* Safety rating: ETL CAT. II 1000V / CAT.III 600V RoHS
Changzhou Skyvictor Import and Export Co., Ltd is one of the professional China exporter for all kinds of the construction lasers and the surveying instruments.
Our product range covers the rotary laser level, the multi-line laser level, the laser distance meter, the theodolite, the total station, etc. The most competitive price, the good product quality as well as the good customer service help us to build up the good company image in the international market.
With many years exporting experiences for the construction laser products, we win the trust from many customers overseas. To achieve win-win situation is always the final business goal we share with each customer.
We are sincerely looking forward to establishing long-term business partner relationship with you!
