Product Specifications
| Prod Model: |
TD-Q12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wavelength And Frequency: |
Short-wave |
| Application: |
Industrial |
| Condition: |
New |
| Standard: |
Standard |
| Screen: |
With Screen |
Product Description
,Main Function
IP67 waterproof protection
Busy channel lockout function
Wide \ Narrow band setting
High \low power switching
VOX function
Squelch level
Dual monitor function
Offset Frequency\direction Setting
Whisper
Talk around
Frequency Step setting
Monitor
DTMF
CTCSS\DCS
Automatic relay function
1750 signalling
Language setting
Keyboard lock
Working mode
Alarm clock
Date &Time Setting
Battery Save Function
APO (Automatic Power Off)
FM Radio Watch
Priority channel Scan
Scan Resume
Flashlight illumination
Low power alert
Power-on password setting
Optional backlight color setting for Rx,Tx,Standby
Automatic contact & call
Channel deleting setting
Channel name editing\display
Transmit begin beep prompt(Begin Beep)
Transmit over beep prompt(ROG Beep)
,Specifications:
Frequency range: 136-174 400-520 MHz
Channel Number: 240
Channel Spacing:25\12.5 KHz
Operating Voltage: 7.4V DC
Dimension (W X H X D): 55.5mm X 119.2mm X 30.5mm (without antenna & battery)
Weight: 127 g (without battery)
Battery : 1700mAh Polymer lithium battery
Frequency Stability: ±2.5 ppm
Operating temperature range :-25ºC ~65 ºC
Antenna Impedance :50 Ω
,Transmitter
Output power UHF:4W\1W VHF:5W\1W
Modulation Mode:16KΦF3E/8KΦF3E
Clutter and harmonics:-36dBm<1GHz-30dBm>1GHz
FM noise≥40/35dB
Audio distortion ≤5%
,Receiver
Sensitivity ≤0.25/0.28μV
Adjacent Channel Selectivity 65/50dB
Intermodulation Resistance 60dB
Sputious Rejection 65dB
Signal to noise ratio 40/35dB
Audio power output 1W
Audio frequency distortion ≤5%
,Accessories
* 1 X Antenna
* 1 X 1700 mAh Polymer Li-ion battery
* 1 X Belt clip
* 1 X Strap
* 1 X User's manual
* 1 X Power adapter
* 1 X Desktop charger
