Product Specifications
| Prod Model: |
ZTS-360R |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East |
| Use Type: |
Mapping Instrument Total Station |
| Minimum Focusing Distance: |
1.2m |
| Single Prism: |
3000m |
| Reflective Sheet: |
800m |
| Measuring Time: |
1.5s |
| Reticle: |
Illuminated |
| Data Format: |
Ascii |
| Operation System: |
Real-Time Operating System |
| Laser Plummet Type: |
Laser Point |
| Weight: |
Approx 3.7kg |
Product Description
Professional Prices Accuracy 2" Mapping Instrument Total Station
The ZTS-360/R is configured with advanced dual-axis compensatorfor auto error elimination and auto accuracy compensation,Diversified data transfer options such as SD card, USB pen drive, mini-B interface
This kind of Hi-Target high precision total station is widely used in surveying and mapping,engineering construction,it's popular in the market for it's high precision,good quality,competitive price,
It can help customers to do most of the work in surveying and mapping.
As for Hi-Target brand Engineering Construction Total Station,it's a yonger products,full of creative and thoughtful sonsideration.It's really a competitive prodcts compete with other brand.
The specifications
| Model | ZTS-360R |
| Angle Measurement |
| Detecting system | Absolute encoder |
| Minimum Display | 1″/5″/10″(selectable) |
| Angle Accuracy | 2″ |
| Telescope |
| Magnification | 30X |
| Field of view | 1°30′ |
| Minimum focus distance | 1.5m |
| Image | Erect |
| Compensation |
| System | Dual-axis |
| Range | ±3′ |
| Resolving power | 1″ |
| Distance measurement(IR) |
| Single prism | 3000m |
| Reflective Sheet | 800m |
| Accuracy | 2mm+2ppm |
| Measuring time (Repete/Tracking) | 1s / 0.5s |
| Reflectorless (RL) |
| Range (white board reflectivity 90%) | 600m |
| Single Prism | >7500m |
| Accuracy | 3mm+2ppm |
| Measuring time | 1.5s |
| Communication |
| Internal memory | 20000 points (SD card supported) |
| Interface | RS232, Mini-USB, USB |
| Data format | ASCII |
| Operation |
| Operation system | Real-time operation system |
| Display | 192×96 high-light LED screen, brightness adjustable in 3 level |
| Keyboard | 2 sides alphanumeric backlit crystal keyboard |
| Laser plummet |
| Type | Laser point, 4 brightness levels adjustment (Optical plummet is optional) |
| Accuracy | 1 mm at 1.5m instrument height |
| Environmental |
| meteorological parameter modification | Manually(T-P senser is optional) |
| Operation temperature | below 20ºC to above 50ºC |
| Storage temperature | below 40°C to above 70°C |
| Dust &Water Proof | IP66 |
| Power supply |
| Battery type | BT30 Li-ion battery |
| Voltage/Capacity | 7.4V 3400mAh |
| Operating time | 18 hours(continuous angle measurement every 30 seconds) |
| Measuring times | Approx. 12000 times |
| Weight |
| Weight | 3.8kg with battery |
| Characters |
| Zenith point measurement without removing the handle |
| Shortcut measurement key on the side, convenient for surveying |
| Small and light |
| Key define |
| Intelligent checking |
What's the advantage of our Mapping Instrument Total Station?
Compact,Lightweight Design
Ensuring the stability of every Indicators of equipment;saving operator's physical exertion in field work
Quick Trigger Button
By pressing it,measurement can finish quickly after targeting the object
Powerful and Fast EDM Capability
Available to reach the target point fast where the data is inconvenient to collect
Dust and Water Protection IP66
Continue to work even in extremely inclement environment
Stable Dual-axis Compensation
Vivid graphic electronic bubble display ensures the high accuracy
Upward Laser Pointing
No dead angle in upward measurement,which is significant for special application
Intelligent Calibration Software
Accessible for real-time diagnosis to ensure trouble-free operation
Compatible Data Format
Compatible to the third-party data process software,satisfying requirements of users for different data formats.
