Product Specifications
| Prod Model: |
ZK various |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation: |
Under Our Engineer's Guide |
| Certificate: |
ISO9001,ISO14000,CE |
| After Sale Service: |
We Offer |
| Application: |
Mining |
| Colour: |
Customized |
| Company Established: |
in 1956 |
| Type: |
Bag Type Dust Collector |
| Mining Object: |
Bag Type Dust Collector |
| Spare Parts: |
We Offer |
| Price: |
Best Price |
Product Description
DMC Seris pulse bag dust catcher
Dust catcher makes up of frame, ash bucket, in-the-box, on-the-box, bag, frame, jet cleaning devices and PLC components such as control procedures. In -the -box is the sub-room structure, while working the gas spread out by the dust collecting duct in all ash bucket.
Coarse particles directly fall into the ash bucket bottom for wind speed reducing and the ash bucket spoiler role in the collision, fine dust rose with the bag at all between the fine dust was blocked leaving the outer surface of the bag, cleaning gas clearance role with negative pressure ventilation through the bag into the mains from the body into the atmosphere, reaching the purpose of purification.
Working Principle:
1. The dust-laden air enters the bag filter.
2. The dust /powder separates inside the bag filter chamber.
3. The air is uniformly distributed avoiding channelling while the powder is separated.
4. Initially a coat of material forms on the bags. Subsequently, the coat acts as the filtering medium.
5. The dust is accumulated on filter elements while the air passes through the filter bags from outside to inside.
6. The accumulated powder is dislodged from the bags by reverse pulsejet air intermittently.
7. The dislodged powder falls on bottom cone and is discharged through powder discharge valves.
8. The dust free air is sucked by induced draft fan and is exhausted to atmosphere.
Bag Filter makes up of frame, ash bucket, in-the-box, on-the-box, bag, frame, jet cleaning devices and plc components such as control procedures. In -the -box is the sub-room structure, while working the gas spread out by the dust collecting duct in all ash bucket. Coarse particles directly fall into the ash bucket bottom for wind speed reducing and the ash bucket spoiler role in the collision, fine dust rose with the bag at all between the fine dust was blocked leaving the outer surface of the bag, cleaning gas clearance role with negative pressure ventilation through the bag into the mains from the body into the atmosphere, reaching the purpose of purification.
The advantages of the bag filter:
The dust removal efficiency of bag filter can reach more than 99.99%, and emission concentration is lower than 50 mg/m3, even less than 10 mg/m3, achieving smoke-free emission, and being close to zero pollution.
(1)the dust removal efficiency is high, generally over 99%
(2)Wide range of handle air volume. It can be used in flue gas dust removal of industrial furnaces, and reduce atmospheric emissions of pollutants.
(3)Simple structure and convenient operation maintenance.
(4) On the premise of guaranteeing the same high dust removal efficiency, the cost is lower than the electric dust catcher.
(5)It can be run in the condition of high temperature above 200 º C.
Henan Zhengzhou Mining Machinery Co., Ltd. Specializes in the production of rotary kiln, ball mill, bag filter, pulse dust and other mining equipment. Supporting the use of these devices can bring considerable economic and environmental benefits for customers.
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://www.inczk.com/ & http://www.zkcomp.com/
24-hour Free Sales Consulting Phone: 861-0371 -5590 2866.
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Price of rotary kiln: http://www.zkcomp.com/calcining/558. Html
Rotary Kiln: http://www.inczk.com/Products/459. Html
Preheater: http://www.zkcomp.com/calcining/605. Html
Cement Mill: http://www.inczk.com/Products/460. Html
Rotary Dryer: http://www.zkcomp.com/calcining/564. Html
Raw Mill: http://www.inczk.com/Products/1373. Html
Ball Mill: http://www.zkcomp.com/grinding/582. Html
Specification
(mm) |
Dispose Air
Volume(m3/h) |
Filtratewind Speed(m/min) |
Filtrat-area(m2) |
Room Number(piece) |
Equipment
Resistance(pa) |
Filter Pocket Specification
(mm) |
Bag
Num-ber(piece) |
Temperat-ure
(°C) |
Cleaning Style |
Systemins-
talvolum
(kw) |
Weight
(t) |
ZL600 |
28800-43200 |
0.8-1.2 |
600 |
3 |
1500 |
Φ130×5150 |
288 |
< 230°C |
off-line pulse cleaning |
100 |
16.5 |
ZL800 |
38400-57600 |
0.8-1.2 |
800 |
4 |
1500 |
Φ130×5150 |
384 |
< 230°C |
off-line pulse cleaning |
140 |
23.6 |
ZL1000 |
48000-72000 |
0.8-1.2 |
1000 |
5 |
1500 |
Φ130×5150 |
480 |
< 230°C |
off-line pulse cleaning |
185 |
27.8 |
ZL1600 |
76800-115200 |
0.8-1.2 |
1600 |
8 |
1500 |
Φ130×5150 |
768 |
< 230°C |
off-line pulse cleaning |
260 |
45.6 |
ZL2400 |
115200-172800 |
0.8-1.2 |
2400 |
12 |
1500 |
Φ130×5150 |
1152 |
< 230°C |
off-line pulse cleaning |
380 |
76.5 |
ZL2800 |
134400-201600 |
0.8-1.2 |
2800 |
14 |
1500 |
Φ130×5150 |
