Product Specifications
| Prod Model: |
MSA141C-S1A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Windings: |
Copper Coils |
| Type: |
Reciprocating |
| Power Source: |
AC Power |
| Configuration: |
Stationary |
| Lubrication Style: |
Lubricated |
| Application: |
Low Back Pressure Type |
| Mute: |
Not Mute |
Product Description
Compressor Data
Compressor Model: MSA141C-S1A
Application: LBP
Refrigerant: R-134a
Design Type: Reciprocating Con-Rod
Refrigerant Control: Capillary tube
Compressor Cooling: Static Cooling
Power Supply: 115V 60Hz
Compressor Rated Performance
Capacity: 144W
Power Input: 101W
COP: 1.43W/W
Test condition(ASHRAE)
-. Evaporating Temp: -23.3C ( -10F)
-. Condensing Temp: 54.4C ( 130F)
-. Ambient Temp: 32.2C ( 90F)
-. Gas superheated to: 32.2C ( 90F)
-. Liquid subcooled: 32.2C ( 90F)
Power source: 220V~50Hz
Standard Part List
ASSY COMBO(MSC)
Terminal Cover
Mounting Accessory (Grommet, Bolt-Hex, Nut-Hex, Washer-Plain, Washer Spring, Sleeve)
Refrigerator compressor, LG compressor, fridge compressor, refrigeration compressor, reciprocating compressor, piston compressor, LG refrigerator compressor
|
Description |
Model |
Capacity |
Input |
COP |
|
HP |
W |
W |
W/W |
|
Samsung refrigerator compressor R134A LBP 115V/60HZ/1PH |
MSA141C-S1A |
1/6 |
144 |
101 |
1.43 |
|
MSA150C-L1A |
1/5 |
177 |
123 |
1.44 |
|
MSA151C-L1B |
1/5 |
177 |
113 |
1.56 |
|
MSA160C-L1A |
1/4 |
217 |
155 |
1.40 |
|
MSA170C-L1B |
3/8 |
256 |
160 |
1.60 |
