Rotary Drier, Drying Machine (2200*18000)

Name: Rotary Drier, Drying Machine (2200*18000)
Brand: china-manufacturer-directory.com
SKU: 683199632
Availability: InStock
Rating: 4.6 (76 reviews)

Supplier:	Henan Yuhong Heavy Machinery Co., Ltd.
Price:	US $ 10000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,EXW,CIF

Product Specifications

Prod Model:	2200*18000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certification:	SGS, CE, ISO9001
Warranty:	One Year
After Sale Service:	for Whole Using Life
Installation:	Engineer Guide and Train Workers
Diameter Of Dryer:	2.2m
Long Of Cylinder:	18m
Shipment:	by Sea or Land
Operational Method:	Continuous
Structure:	Rotary Type Drier
Operation Pressure:	Atmospheric Dryer
Movement Way:	Fixed
Heating Mode:	Transmission

Product Description

Introduction:
Rotary drier is widely used for drying materials in industries like cement, mine, building materials, chemistry, food and fertilizer, etc. This rotary drying machine comes with thermocouples on the feeding and discharging device to control the temperature
Rotary drier is mainly composed of cylinder, under frame, feeding and discharging devices, transmission device, gear cover, etc. (Optional auxiliary equipment includes combustion chamber, feeder and discharging device, and dust collection equipment). Rotary drier manufactured by us adopts new lifting plate, which is of functions like guiding, current-sharing, and material rising. The materials are raised and evenly drop so that they are in full contact with heat for better drying efficiency. Our rotary drier is designed with the best working conditions, which enables it to save 10-15% of energy and increase 10-15% of productivity compared with common dryers.

Principle:
Materials are sent to hopper of rotary dryer by belt conveyor or bucket elevator. The barrel is installed with slope to horizontal line. Materials enter the barrel from the higher side, and hot air enters the barrel from the lower side, materials and hot air mix together. Materials go to the lower side by gravity when the barrel rotates. Lifters on the inner side of barrel lift materials up and down to make materials and hot air mix completely. So drying efficiency is improved.

Feature:
High heat transfer coefficient and high thermal efficiency
Large treatment capability, wide application
Well drying effect
Indirect-heating, no material contamination
Retention time can be adjusted, low energy consumption
Convenient operation and easy maintenance

Model ( mm )	Gradient ( % )	Rotation Speed ( r/min )	Feed-in Gas Temperature ( ºC )	Power ( kw )	Output ( t/h )	Weight ( t )
Φ600x6000	3-5	3-8	≤700	3	0.5-1.5	2.9
Φ800x8000	3-5	3-8	≤700	4	0.8-2.0	3.5
Φ800x10000	3-5	3-8	≤700	4	0.8-2.5	4.5
Φ1000x10000	3-5	3-8	≤700	5.5	1.0-3.5	5.6
Φ1200x10000	3-5	3-8	≤700	7.5	1.8-5	14.5
Φ1200x12000	3-5	3-8	≤700	11	2-6	14.8
Φ1500x12000	3-5	2-6	≤800	15	3.5-9	17.8
Φ1800x12000	3-5	2-6	≤800	18	5-12	25
Φ2200x12000	3-5	1.5-6	≤800	18.5	6-15	33
Φ2200x18000	3-5	1.5-6	≤800	22	10-18	53.8
Φ2200x20000	3-5	1.5-6	≤800	30	12-20	56
Φ2400x20000	3-5	1.5-5	≤800	37	18-30	60
Φ3000x20000	3-5	1.5-5	≤800	55	25-35	78
Φ3000x25000	3-5	1.5-5	≤800	75	32-40	104.9
