Single-Sided Flexible Printed Circuit Board

Name: Single-Sided Flexible Printed Circuit Board
Brand: china-manufacturer-directory.com
SKU: 724739125
Availability: InStock
Rating: 4.8 (29 reviews)

Supplier:	Xiamen Bolion Circuit Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	S7475
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimensions:	179.00 * 23.00mm
Thickness:	0.12mm

Product Description

Single-layer FPCs with FR4 Stiffener

Model: S7475
Type: Single-sided FPCB
With FR4 stiffener
Material: 1oz CU (RA)/20um ADH/25un PI
Cover layer: 25um PI/25um ADH
Stiffener: PI, 0.8mm FR4
Thickness: 0.12mm
Surface treatment: plating tin 2 to 8um
Dimensions: 179 x 23mm
Width/space: 0.5/0.37mm

Process capability:

Base film thickness:
Polyamide: 12.5/25/35/50um
Polyester: 12.5/25/35/50um
Copper thickness: 12/17.5/35/50/70/105um
Minimum line width/line space: 0.075/0.075mm
Minimum hole size: 0.2mm
Tolerance: outline ±0.05/cover layer ±0.2mm
Peel strength:
Polyamide: above 1.0kgf/cm
Polyester: above 0.8kgf/cm
Solder resistance:
Polyamide: 260°C/10 seconds
polyester: 204°C/5 seconds
Certificates: UL, TS16949
Meets RoSH and WEEE lead-free requirement

Advantage:

1. Over 10 years' manufacturing experience
2. Assembly provided
3. 100% quality tested before shipment
4. Certificate of UL, ISO9001, ISO14001 and ISO/TS16949.
5. Our Products meet the RoHS & WEEE lead-free requirement.
6. Small Order accepted
7. 3 weeks for massive production; 10 days for sample since material prepared
Urgent case or spread delivery schedule will be updated per negociation then

FPC Apply:

medical apparatus
automobiles
aerospace
industrial equipment
detecting instruments
smart-home controller
consumer electronics, etc

Main Technique Index
Description	Parameters
Description	Polyimide	Polyester
Base film Thickness (um)	12.5,25,35,50	12.5,25,35,50
Copper Thickness (um)	12,17.5,35,50,70,105
Min. Line Width/Line Space (mm)	0.075/0.075
Min. Hole Size (mm)	0.15
Tolerance (mm)	Outline:+/-0.05; Coverlay: +/-0.2
Peel Strength (kgf/cm)	Above 1.0	Above 0.8
Solder Resistance	260C 10 seconds	204C 5 seconds

Surface Treatment
Content	Normal coating thickness	Normal PNL size
Plating nickel gold (In house)	Ni:2-9um;Au:0.03-0.09um	300mm×400 MM
Plating hard gold (In house)	Ni:2-9um;Au:0.1-1.0um	300mm×400 MM
Plating soft gold (In house)	Ni:2-9um;Au:0.03-0.09um	300mm×400 MM
Plating pure tin (In house)	2.0-8.0um	300mm×400 MM
Immersion Tin (In house)	0.3-0.6um	300mm×400 MM
OSP (In house)	N/A	300mm×400 MM
ENIG (Hard Nickel) (In house)	Ni:2-6um;Au:0.03-0.10um	300mm×400 MM
ENIG (Soft Nickel) (In house)	Ni:2-6um;Au:0.03-0.10um	300mm×400 MM
ENEPIG (Hard Nickel) (In house)	Ni:2-6um;Au:0.03-0.10um	300mm×400 MM
HASL (Outsource)	Cover the pads with min thickness 1~2 um	300mm×400 MM
Immersion silver (Outsource)	Per standand creteria	300mm×400 MM
