SMD3535 P10 Full Color Outdoor LED Display with High Brightness
Product Specifications
| Prod Model: |
P10-outdoor SMD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LED Encapsulation: |
SMD3535 |
| Module Size: |
320X160mm |
| Module Resolution: |
32X16dots |
| Protection Grade: |
IP65 |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
10mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
350W / m² |
| Pixel Density: |
10000 dot / m² |
| Scanning Mode: |
1/4 Scan |
| Display Type: |
LED Video Display |
| Certification: |
RoHS |
| Application: |
Advertising,Stage Performance,Rental |
Product Description
P10 SMD3535 outdoor full color led display screen for rental or permanent install,with high brightness,good display performance and competitive price
1. SMD led encapsulation confirm wide view angle and slim thickness
2. Anti-corrosion,antifogging,and good waterproof IP65,long life span
3. High pixel density, Long view distance, High definition, Good uniformity
4. Lower power consumption and energy saving,good enironment protection
5. Can be fixed on the wall, on the street, or for rental to meet the request of live broadcast, live meeting, banquet, party, etc, to display the content what you want, by video, graphics, antimation etc, connect with PC computer or network, also can remoto control with asynchronous system.
6.Widely used for commercial led display,advertising led display, stage led display,mobile led display. traffic led display,rental led display, sports led display etc.
| Outdoor P10 Full Color LED Display Main Parameters |
| Visual Characteristics | Unit | Value |
| Pixel Pitch | mm | 10.0 |
| Pixel Density | Dots/sq.m | 10000 |
| Pixel Configuration |
| SMD3535 |
| Cabinet Resolution | dots | 80×80/128×96 |
| Refresh Rate | Hz | ≥1800 |
| View Angle(H/V) | ° | 140/140 |
| Brightness | nits | ≥5500 |
| Gray Scale | Bit | 16 |
| IP Rating |
| 65 |
| Power Consumption(Max/Avg) | W/sq.m | 1000/300 |
| Input Voltage(AC) | V | 110~240 |
| Modular Characteristics |
| Cabinet Size(W×H×D) | mm | 800×800/1024χ960 |
| Cabinet Material |
| Aluminum/Iron |
| Cabinet Weight | Kg | 35/40 |
| Module Size(W×H) | mm | 320×160 |
| Environment |
| Operation Temperature | ºC | -20~+40 |
| Operating Humidity |
| 10%~90% |
| Driving Mode |
| 1/4 Scan |
| Control Distance | Cat 5E <100m,Single mode fiber<10Km |
