Socket Block CATV Splice Connector 5/8 Ff CATV Connector
| Price: |
US $ 0.1-0.3/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
5/8 FF Socket Block CATV Splice Connector
A. Socket Block CATV Splice Connector Description:
CATV Connector, 5/8 Female-5/8 Female soket splice block connector.
B. Socket Block CATV Splice Connector Features:
1. Manfactured of high quality brass with nickel plating of superior protection against v-corrosion
2. Designed to be watertight for outdoor applications
3. Offer excellent RFI shielding properties easy-grip free-spinning nut for fast installation and installer comfort
C. Business Scope: ( CATV Splice Connector)
We deal with all connector: TV connector, TV jack connector, antenna connector, coaxial connector, F connector, RF connector, CATV connector, BNC connector, catv f connector...Etc. All production are cheaper than other company. Meanwhile, our pruduction are high-qualty. There are so many choice in our company.
D. Technical Characteristics of CATV Splice Connector
|
Frequency Range |
DC~1000MHz |
|
Working Voltage |
335V max |
|
Withstand Voltage |
750V rms |
|
Contact resistance |
|
Center Contact |
≤ 10 mΩ |
|
Outer Contact |
≤ 5 mΩ |
|
Insulation resistance |
≥ 1000 MΩ |
|
Durability(mating) |
≥500(cycles) |
|
Temp.range |
-50~+60°C |
| Prod Model: |
5/8 FF CATV Connector |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: |
CE,FCC,RoHS |
| Length: |
18mm or 20mm |
| Impedance: |
75ohm |
| Bandwidth: |
0-1000MHz |
| Style: |
5/8 Female-5/8 Female Soket Splice Block Connector |
| OEM: |
Welcome |
| Type: |
Generally Coaxial Connector |
| Coupling Mechanism: |
Threaded Connection |
| Brand: |
Daytai |
| Classification: |
Female to Female |
