Features:
1. Using Digital MCU technology to confirm the machine can be working very
well in the poor voltage situation or generator (working voltage from 270V-460V, normal hardware machine has been breakdown below 340V).
2. Using high performance MCU, speedy, excellent real-time response;
3. Adopt IGBT & advanced PWM Inverter technology;
4. High duty cycle, high efficiency;
5. Anti-sticking, arc force, hot start;
6. Compact, light weight, portable;
Compatible POWER GENERATOR, VRD, EMC, LIFT TIG, CEL (Cellulose
electrode: E6010, E7018) function;
(Add different function module, the parameter and weight will change,and
also will be extra charged.)
7. Intelligent Protection: over-voltage, low-voltage, over-current, over-heat;
Application:
1. Suitable for most industrial metals and alloys welding;
2. Applicable electrode diameter: ¢1.6- 5.0mm;
Parameters:| Item | ARC250Gen | ARC300Gen | ARC315Gen |
| Rated Input Voltage(V) | AC400±15%(3PH) | AC400±15%(3PH) | AC400±15%(3PH) |
| Input Frequency(Hz) | 50/60 | 50/60 | 50/60 |
| Rated Input Power(KVA) | 9.5 | 11 | 12 |
| Rated Input Current(A) | 11.4 | 16.7 | 18.0 |
| Welding Current Range(A) | 10 ~250 | 10 ~300 | 10 ~315 |
| Arc Force Current Range(A) | 0-100 | 0-100 | 0-100 |
| Rated Output Voltage(V) | 30 | 32 | 32.6 |
| No-load Voltage(V) | 56 | 62 | 65 |
| Duty Cycle Imax(25ºC) | 60% | 60% | 60% |
| Duty Cycle 60%(25ºC) | 250A | 300A | 315A |
| Efficiency(%) | 88 | 88 | 88 |
| Protection Class | IP21 | IP21 | IP21 |
| Insulation Class | F | F | F |
| Electrode Diameter (mm) | 1.6~5.0 | 1.6~5.0 | 1.6~5.0 |
| Weight(Kg) | 8.42 | 8.42 | 8.42 |
| Dimension(mm) | 372*150*280 | 372*150*280 | 372*150*280 |
| Prod Model: |
ARC250Gen/300Gen/315Gen |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Welding Machine, MMA Welder: |
Inverter Welding, DIY Welding |
| Type: |
ARC Welders |
| Current: |
Inverter Current |
| Application: |
Inverter Welding Machine |
