Features:
1. Using Digital MCU technology to confirm the machine can be working very
well in the poor voltage situation or generator (working voltage from 95V-260V, normal hardware machine has been breakdown below 180V).
2. Using high performance MCU, speedy, excellent real-time response;
3. Adopt IGBT & advanced PWM Inverter technology;
4. High duty cycle, high efficiency;
5. Anti-sticking, arc force, hot start;
6. Compact, light weight, portable;
7. Intelligent Protection: over-voltage, low-voltage, over-current, over-heat;
Application:
1.Nuclear power installation, pipe installation, petrochemical,
2.Shipbuilding, automobile, boiler, pressure vessel, aviation, etc.
3.Apply to all position welding of stainless steel, carbon steel, alloy steel, copper,
4.Titanium, and other plates Used by DIY'er
Parameters:
| Item | DTIG-160S | DTIG-160A | DTIG-160P |
| Rated Input Voltage(V/Hz) | AC230V (1PH) | AC230V (1PH) | AC230V (1PH) |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 |
| Input current Range (A) | 19 | 19 | 19 |
| Output current Range (A) | 10-200 | 10-200 | 10-200 |
| No-load Voltage (V) | 42 | 56 | 56 |
| Rated Output Voltage(V) | 18 | 18 | 18 |
| Pulse Frequency (Hz) | - | - | 0.5-500 |
| Pulse Width Range (%) | - | - | 10-90 |
| Pre Flow Time (S) | 0.1-1 | 0.1-1 | 0.1-1 |
| Post Flow Time (S) | 0.1-6 | 0.1-6 | 0.1-6 |
| Up slope Time (S) | 0-6 | 0-6 | 0-6 |
| Down slope Time (S) | 0-6 | 0-6 | 0-6 |
| Duty cycle (%)(25ºC) | 60 | 60 | 60 |
| Duty cycle (100%)(25ºC) | 154 | 154 | 154 |
| No Load Loss(W) | 35 | 35 | 40 |
| ARC-starting | HF | HF | HF |
| Efficiency(%) | 88 | 88 | 88 |
| Protection Class | IP23 | IP23 | IP23 |
| Welding Thickness(mm) | 0.3-6 | 0.3-6 | 0.3-6 |
| Insulation Class | B | B | B |
| Weight(Kg) | 7.7 | 7.7 | 7.7 |
| Dimension(mm) | 400*150*260 | 400*150*260 | 400*150*260 |
Established in 2000, Shenzhen G-Weld Electrical Appliance Co., Ltd, is one of the leading manufactures and exporters, specializing in R& D, production and selling of inverter welding machines, air plasma cutting equipment, stud-welding machines and accessories. Our company is situated in Shenzhen Special Economic Zone, close to Hongkong and Macau, and very convenient for transportation by Sea, Land and Air.
Using the latest inverter technology including hardware & software, our products have three major advantages: Smallest size, light weight and perfect performance. Currently, we possess 13 series of product categories with more than 50 models, including Inverter MMA, TIG, MIG, CUT & STUD-Welding series etc.
Our company has obtained CE, CCC and ISO9001: 2000 certificate. The reliability and stability of our products is what concerns most. We offer quality warranty to protect customers? Profit and try to maximize customers? Satisfaction. With excellent quality, competitive price and optimal service, our products are popular in the international market, such as, China, Southeast Asia, Europe, South Africa, Middle East and America etc.
With the development of more than ten years, our company has formed its own business philosophy---Technology Innovation, Excellent Quality, Prompt Response, and Customer Appreciation, and we will try our best to meet the requirement of customers & market. Meanwhile, we sincerely hope we are going to head into a better future together with you.
