Guangzhou Sanway Professional Audio Equipment Co., Limited >> Sp480 4 in Audio Processor, DSP Processor

Sp480 4 in Audio Processor, DSP Processor

Name: Sp480 4 in Audio Processor, DSP Processor
Brand: China-Manufacturer-Directory.com
SKU: 690086032
Availability: InStock
Rating: 4.8 (124 reviews)

Supplier:	Guangzhou Sanway Professional Audio Equipment Co., Limited
Price:	US $ 400-500/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,EXW

Product Specifications

Prod Model:	Sanway SP480
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	4 in & 8 Output Processor
Power:	25 Watts
Power Supply:	AC 110V/220V 50Hz/60Hz
Noise:	<95dB
Application:	Commercial
Certification:	RoHS
THD:	0.005%-0.01%

Product Description

4 In Audio Processor, SP480 Digital Speaker Management Processor

1) 96k Hz sampling frequency, 24-bit A/D and D/A converter, 32-bit DSP processor
2) Input channel With 6-band parameter EQ, Delay, polarity
3) Output channel With 6-band parameter EQ, Gain, Delay, Polarity, Crossover,
Limiter/Compressor, Signal select.
4) Build in USB & RS 485 COM
5) Program Function; Recall Function; Copy Function; Save Function; Password Function.
6) 6-band EQ: Frequency, gain & Q fact are adjustable;
Gain can be adjusted from -20 dB to +20 dB.

Model	SP480 4input&8output Digital Speaker Management
Input Impedance	Balance: 20KΩ
Output Impedance	Balance: 100Ω
PC Com Port	One USB Com Port on front panel, 2 Rs485 Com Port on back panel(RJ-45)
CMRR	>70dB@1KHz
Input Level	≤+25dBu
Frequency Response	20Hz~20KHz ±0.5dB
S/N R	>110dB
THD	<0.01% @OUTPUT=0dBu/1KHz
Crosstalk of Channels	>80dB@1KHz
Delay Time Step	Each input channel has independent delay control, Range:0~1000mS; 21μS step@0~10mS; 84 μS step@ 10mS~20ms; 0.5mS step@ 20mS~1000mS
Input/Output Polarity	In-phase(+) or reversed phase(-)
Input EQ	6-band parameter EQ; Frequency: 20Hz~20KHz; Gain:-20 dB~+20 dB; Bandwidth: 0.05oct~3oct
Mute	Mute with each Input& Output channel
Input Selection	Each input channel can be selected to each output channel
Output Gain	Range:-12dB~+12dB, step: 0.1dB
Crossover	Each output channel can be independently set as LPF and HPF. The parameters can be adjusted. Filter type :Linkwitz-Riley; Bessel; Butterworth. The Crossover Frequency: 20Hz~20KHz, Slope: 12dB/oct; 18dB/oct; 24dB/oct;48dB/oct.
Limiter	Limiter with each output channel. The parameters are adjustable: Threshold value: -20dBu~+20dBu; step:0.5dBu. Attack time: 0.3mS~100mS. 0.1mS step at 0.3~1mS; 1mS step at1mS~100mS. Release Time: Release Timecan be set as twice, 4times, 6times, 8times, 16times, 32times.
Output EQ	Each output channel has 6-band EQ: 3 modes: Lo-Shelf/Hi-Shelf/Parameter. A: Lo-Shelf: Slop: 6dB/12dB; Frequency:20Hz~20kHz; Gain: -20dB~20dB; B: Hi-Shelf: Slop: 6dB/12dB; Frequency: 20Hz~20kHz; Gain:-20dB~20dB; C: Parameters:frequency: 20Hz~20KHz, bandwidth: 0.05oct~3oct; Step: 0.05oct; Gain: -20dB~+20dB, Step 0.1dB
Processor	96KHz Sampling frequency, 32-bit Floating-Point DSP
Display	With 2*24 LCD, 8-LED input/output level. Mute and Editing mode can be displayed.
Power	≤25W
Power Supply	AC 110V/220V 50Hz/60Hz
Dimension(L×W×H)	482×232×44mm
Gross Weight	5.0kg

Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.

With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.

Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.

Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.

Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.

We always keep and follow the principle to do business:

The same product, we win by the quality;

The same quality, we win by the price,

The same price, we win by the service.

We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.

Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
