Product Specifications
| Prod Model: |
RAY-60 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
710mm X 560mm X 252 Mm |
| G.Weght: |
65kg |
| Detection Method: |
Spectrophotometer |
| Principle: |
New Spectrometer |
| Wavelengths: |
Infrared Spectrometer |
| Dispersive Element: |
Interferometer Spectrometer |
| Light Number: |
Monochromator |
Product Description
Functions:Set the parameter, baseline scan, spectrum scan, fixed point measure, measure the Spectrum and spectral smooth, spectral differential, Spectral calculation, read data, Peak detection and so on.
Specifications:Wavelength range: 800 nm - 2500 nm;
Wavelength accuracy: ± 1.5 nm;
Wavelength repeatability: 1.0 nm
Resolving power: ≤ 0.8nm (on1000nm, slit 0.2mm)
100% Line Straightness: ± 0.5 %T
Stray light: ≤ 1%T( on 1690 nm )
Spectral bandwidth: Wide\normal\narrow\very narrow
Scan interval: 2.0nm, 1.0nm, 0.5nm, 0.2nm, 0.1nm
Measure mode: Absorbance, transmittance, energy
Scan speed: Very fast, fast, medium, Slow and very slow
Scan mode: Repeatedly scan, continuously scan, time scan
Dimensions: 710mm x 560mm x 252 mm
Pondera: 62 kg
Power requirements: 220V± 22V, 50Hz± 1 Hz
Computer: General computer with two interface of Universal Serial Bus
Raylabel Ltd., founded in 2005.
We are a professional manufactures laboratory equipments, medical apparatus and school furniture which have a very powerful R&D team and now becoming the professional Lab equipments total solution provider in this field. Our company has obtained ISO9001: 2000 and ISO13485: 2003 certificate of quality management system registration approval. Raylabel products show extremely long life span and stability in the function.
All the sale engineers from Raylabel Ltd., have strong professional experience. Some of them have been more than 15 years. Our company operates its business with the management philosophy of "customer first, service forever". We are proud of the supporting with our perfect quality of products and timely service systems. And we sell our products to all parts of the country and overseas.
Based on the global instrument market awareness and marketing strategies, Raylabel products are increasingly becoming excellent OEM supplier and partner, We will based in China to provide more advanced and high quality products and better service.
Our goal is to be an international lab equipments and school furniture supplier worthy of trust, and we are dedicated to benefiting our customers by minimizing their cost with reasonable prices and maximizing their profits with trouble free products.
Choose "Raylabel", Choose a Most Valuable Business Partner!
