1. Working voltage rating: 4± 0.5V;
2. Working pulse width rating: ≥ 80MS;
3. Rated working pulse interval: ≥ 50MS;
4. Coil resistance: 430± 5%ohm; (23± 2)
5. Velocity ratio100: 1; 200: 1; 400: 1; 800: 1
6. Stepping angle: 3.6; 1.8; 0.9; 0.45 degree
7. Step motor driving torque: 30 u Nm;
8. Specifications(quantity of character wheel): 5+1 (5 integers + 1 decimal);
9. Character wheel material PC
10. Rotating direction of character wheelclockwise rotation only
11. Lead length: 90mm or on your request
12. Range of working ambient temperature: -40~70
13. Variable-speed gear material: Polyoxymethylene
14. Base frame material: Plastic base frame: PC
15. Motor stator material: Ferronickel alloy
16. Shielding cover material: Low-carbon steel shielding cover
17. Error-free working period: ≥ One billion pulses
18. Installation dimension: Two upper holes 24.5× 35mm, 19, single metal shielding: 0.5mm thickness
