| Supplier: | Zhejiang People High Voltage Electrical Ceramics Co., Ltd. |
|---|---|
| Price: | Negotiable |
| Min Order: | 1 /Piece |
| Quantity:: | |
| Trade Terms: | by sea |
|
|
| Prod Model: | BYD-B |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type | BYD5-220/2 | BYD10-380/4 BYD20-380/4 | ||
| Rated working voltage Un(V~) | 220V | 380V | ||
| Continuous operating voltage Un(V~) | 275V | 320V | 320V | |
| Protection level Un(V~) | ≤ 0.7 | ≤ 0.1 | ≤ 1.1 | ≤ 1.2 |
| Standard discharge current (8/20μ )In(KA) | 5 | 10 | ||
| Max current capacity max (8/20μ S )In(KA) | 10 | 20 | ||
| Response time(nS) | 25 | |||
| Working environment | -40~+85 | |||
| Relative humidity | 95%(25º C) | |||
| Connection lead cut-area (mm² ) | ≥ 10 | ≥ 16 | ||
| Groud wire cut-area (mm² ) | ≥ 16 | ≥ 25 | ||
| Warning wire cut-area( (mm² ) | ≥ 1.5 | |||
