Product Specifications
| Prod Model: |
PAC100-220S12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Environmental Standard: |
Accord with RoHS |
| Output Type: |
Single |
| Input Voltage: |
220V |
| Voltage Regulating Mode: |
Width Modulation Type |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Separate-excited Switching Power Supply |
| Warranty: |
2 Years |
| Power Supplying System: |
Terminal Power Distribution Equipment |
| Certification: |
ISO |
| Output Power: |
100W |
| Brand: |
Pengtu |
Product Description
PAC-100 Power Supply with PFC Function Series 100W
Features
Universal AC input voltage
Built-in active PFC function, PF>0.95
Efficiency is as high as 90%
No-load loss<0.5W
With short circuit protection / overload protection / over-voltage protection / Optional over temperature protection
With reference to the international safety Certification: UL/ TUV/ CB/ CE
Built-in constant-current limiting circuit
Naturally Air-cooled
1 U height 38 mm
With the far end pull shutdown function (optional)
All capacity are 105º C long life capacitance
100% full burn-in test
Using lead-free process, accord with environmentalProtection RoHS requirement main index
Input Characteristic
Input voltage range...90 ~ 264VAC / 120 ~ 370VDC
Input inrush current...Cold start, 35A / 115V, 65A / 230V
Output Characteristic
Adjustable extent of output voltage...Rated output voltage -5~10%
Power factor...PF>0.95/230VAC, PF>0.98/115VAC (full load)
Leakage current...<1mA / 240VAC
Overload protection...Over current point in 105% ~ 150% when constant current limit flow, self-reset
Over-voltage protection...Rated output voltage of 115% ~ 145% when shut off, self-reset
Over temperature protection...90º C(3.3V~7.5V). 85º C(12V~48V) (Power bridge radiator temperature) turn off, the temperature drop resume automatically, rise. Keep time with 230 VAC 2500 ms, 100 ms, 50 ms
General Characteristic
Insulation characteristic...Input and output: 3KVAC, input and case: 1.5KVAC, output and case: 0.5KVAC 1 minute
Operating temperature...-40 ~ +60º C (See the output drop load curve)
Anti vibratility...10~500Hz, 5G 10 minutes / cycle, XYZ each axis every 60 minutes.
Safety Certification...Reference through the UL60950-1, TUV en60950-1 certification
EMC Standards...EN55022(CISPR22) class B, EN61000-3-2, -3 EN-61000-4-2.3, 4, 5, 6, 8, 11, EN61000-6-2 (EN50082-2), Class A heavy industry standard
MTBF≥ 200000 h, MIL-HDBK-217F (25º C)
Mode of connection...7P / 9.5 mm Belt cover teminal row
Weight & Package...0.38PKG/PCS; Each box 24 PCS / 10.1 KGS, 0.0215CBM
Storage temperature...-40º C~ +85º C
|
Input Voltage(VAC) |
Input Voltage(Range) |
Output Voltage(VDC) |
Output Current(A) |
Pk-pk(mv)
Ripple and noise |
Efficiency |
Models |
|
220 |
90~264 |
3.3V |
20 |
80mv |
78 |
PAC100-220S3.3 |
|
220 |
90~264 |
5V |
17 |
80mv |
83 |
PAC100-220S05 |
|
220 |
90~264 |
7.5V |
13.5 |
100mv |
84 |
PAC100-220S7.5 |
|
220 |
90~264 |
12V |
8.5 |
120mv |
88 |
PAC100-220S12 |
|
220 |
90~264 |
15V |
7 |
150mv |
88 |
PAC100-220S15 |
|
220 |
90~264 |
24V |
4.5 |
150mv |
89 |
PAC100-220S24 |
|
220 |
90~264 |
36V |
2.9 |
200mv |
89 |
PAC100-220S36 |
|
220 |
90~264 |
48V |
2.2 |
240mv |
90 |
PAC100-220S48 |
Nanjing Pengtu Power Supply Co., Ltd was established in 2007, is located in NO. 26 Daxiaochang Road, Qinhuai District, Nanjing, China. Our company is a manufacturer specializing in power product development, design, production, sales and service company. Our company has R&D, Production, Marketing, Quality Control department and other functional departments, And has a number of high-tech talents, which college degree or above of our personnel is more than 50% of the total number of employees. Our company has not only passed ISO9001-2008 Quality System Certification, and some products through the Measurement of Jiangsu Province Academy of Sciences and National Electric Power Academy of Sciences and other authorities detection. Product safety and electrical properties fully comply with the Ministry of Information Industry YD/T731-2000 High Frequency Switch Rectifier Standard.
In the power supply field, our company has independent research and development of AC/DC, DC/DC switching power supply module series mature products, power covers 3W-1000W. And our company strictly reference (GJB9001A - 2001) Nations Standard Quality Management System requirements, design and produce the special specifications of the power supply for the army and common customer.
Since its establishment to now, our company adhere to the science and technology as the forerunner, take the technology as the backing, and constantly develop all kinds of hi-tech leading colleague' S new products. Currently we has a number of national patent. Our company produces the "PengTu" brand power has been widely used in railway, military, aerospace, power, communication, control, instrument, car equipment, ship and major scientific research institutions, etc various fields, from the customer high praise.
We will always remember the"quality first service first" business philosophy, to provide users with convenient one-stop service. With our practical, innovation, refinement spirit of enterprise, we accelerate the company' S technical innovation and product development and at the same time we will with more quality products, more detailed services and more excellent results return to the vast number of customers. Let us work together to create you and I better tomorrow.
