Product Specifications
| Prod Model: |
TC-MT-1000T |
| Dimension: |
200mm X 176mm X 50.2mm |
| Type: |
Energy Meter |
| Display: |
Digital |
| Electric Equipment: |
Three-phase Four-wire |
| Theory: |
Electronic Meter |
| Installation: |
Direct Connected |
| Usage: |
Maximum Demand Meter |
| Measured Signal: |
Pulse Peak |
| Power Meter Connection: |
Terminal |
Product Description
TCE-MT-1000T three phase four wire electronic meter developed by Techen Electronic is a basic energy meter type for residential, commercial and light industrial applications. The meter accurately measures the four quadrants active and reactive energy, the various instantaneous values, and with the functions of flexible tariff, period frozen data, event log, anti-tamper. Manufactured with the advanced SMT technology and all-around test process, ensure the meter with high accuracy, effective cost, and stable performance.
Technical Specification:
Rated Voltage (Un): 3 x 220/380V
Normal Operating Voltage Range: 70%Un ~ 120%Un
Rated Current: 5(60)A, 10(80)A, 10(100)A
Accuracy: Active class 1.0, reactive class 2.0(optional)
Starting Current: 0.004Ib
Pulse Constant: 1000imp/kWh, 1000imp/kvarh(optional)
Frequency: 50Hz
RelativeHumidty: ≤ 95%
Voltage Circuit Power Consumption: ≤ 1.5W, 10VA
Current Circuit Power Cosumptin: ≤ 1VA
Protection grade: IP54
Electostatic Shock: Contact discharge 8kV, air discharge 15kV
Insulation: Resist 4kV, 50Hz for 1 min
Pulse Voltage: 8kV
Main Features:
-- Measure active energy, reactive energ (optional)
-- TOU tariff, TOD tariff, selectable.
-- Various anti-tamper function: Meter cover open, terminal cover open, bypass, reverse energy, neutral loss(optional), earth connected, etc.
-- Load control function: Power limit value and sensitive relay on/off control.
-- Large Non-volatile memory capacity available for mass data storage
-- Mass load profile and event log functon
-- Meter cover is fixed to meter base with buckles instead of screw, open the meter cover by force will cause visible damage to the meter structure.
-- LCD display, show various data information
-- Back-up battery, support LCD reading under powr failure status
-- Real time clock, leap year switch automatically
-- Meter reading and parameter setting via optical port or RS485
