Product Specifications
| Prod Model: |
KLE-4024R, ultrasonic cleaning machine |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Ultrasonic Cleaning Machine: |
Recycling Ultrasonic Cleaning Machine |
| Style: |
Integrated Style |
| Physical Machine Type: |
Ultrasonic Cleaning Machine with Filtering & Cycli |
| Usage: |
Auto Industry |
| Machine Type: |
Industrial Ultrasonic Cleaner |
| Clean Type: |
Industrial Ultrasonic Cleaner |
| Cleaning Process: |
Hot Water Cleaning |
| High Pressure Cleaner Type: |
Ultrasonic Cleaning Machine with Filtering & Cycli |
| Certification: |
Array |
Product Description
Ultrasonic Cleaning Machine with Filtering & Cycling
KEEPLEADER™ SERVICE
ABOUT PRODUCT
Customized design; Safe and convenient operation and maintenance
ABOUT FACTORY
Comprehensive management process, leading technology and service team
EXPERIENCE
Internationalization of business process; Rich experience of Non-standard design
AFTERSERVICE
Uniform standard with special difference for each, Professional and Experienced service
MARKET
Yearly 30% Market share increased, One-to-one service
Note:
Please tell us following information:
* The size of internal cleaning tank you wanted
*What's your cleaning parts and its contamination?
*Your expected cleaning efficiency and cleaning effect
MACHINES' INTRODUCTION AT KEEPLEADER™
| Ø Advantage |
| Single tank ultrasonic recycle cleaning machine, is used in working shop to clean small heavy oiled hardware, there is two Champers, one is used in pre-washing with detergent to remove oil, the other champers is for refined cleaning by hot water, separated cleaning method can save detergent and improve cleaning effect |
| Ø Detailed parameter |
| Name | Ultrasonic recycle cleaning machine |
| Model | KLE-4024R |
| Application | Heavy oiled small hardware |
| Auxiliary | With Water recycle System (optional) |
| Ultrasonic power | >1200W*2 |
| Heating power | >4KW*3 |
| Vibrator standard | 40khz,60W/pc |
| Power supply | 380V,50HZ |
| Size of inner cleaning tank | 650*400*500mm(L*W*H) |
| Control mode | Mechanical |
| Heating temperature | 0 up to 110 adjustable |
| Vibration mode | Side vibration |
| Heating mode | Heating rod at the corners |
| Cleaning basket | Stainless steel, the mesh>10*10mm |
| Switch | Separated Power Switch, Ultrasonic SW and Heating SW |
| Configuration | Assembled Four Universal wheel |
| Separated lid/Cap |
| With cleaning Basket |
| Each generator has power wire of 5m |
| High Q value(NTK made in Japan) Vibrators |
| Stainless steel Drain valve assembled under the bottom |
| Automatic frequency tracking Generator |
| Over-current protection |
| Soft-start function |
| Ø Material |
| Inner cleaning tank | SUS304#2.0mm |
| Vibrating side | SUS 304#,2.5mm |
| Surrounded outside | SUS 304#,2.0mm |
| Base support | Stainless steel Square tube 38mmx38mm,1.5mm |
| DC Connector | CHINT |
| Ø Process standard |
| Vibration side | Hard chrome plated≥0.05mm |
| Appearance | No glitches, no corners, smooth, beautiful |
| Inner cleaning tank | Well welded, upright, water-proof |
| Welding spot | No burn marks, welding marks after polishing |
| Fixed screw | Ball head smooth |
| Assembled mode of vibrator | Glued + Screwed |
| Heating rod | Well insulated, short-cut protected |
| Ø Free spare parts |
| Separated generator, heating rod, fuse |
| Ø Packing |
| Wooden case with pallet, easy operated by fork Supported under the bottom avoid impacting during delivery Stretch seal around |
MFR: KEEPLEADER™ have modified and designed model for our customers' unique and special requirements, please contact KEEPLEADER™ for updated details
SERVICE PROCESS AT KEEPLEADER™
the clients offer information of the workpieces being cleaned (eg: picture, materials, sizes, requirements, etc) if have samples, it's better to send KEEPLEADER™ some sample to perform the cleaning test, if can be cleaned, we provide offer sheet, once confirmed, sign a contract, the clients paid the deposit, KEEPLEADER™ start equipment building, after passing the acceptance, and receive the balance payment, KEEPLEADER™ delivery the device to clients
AFTER SALES SERVICE AT KEEPLEADER™
After purchasing at KEEPLEADER™ is first step of our after-service, all of machines at KEEPLEADER™ has one year guarantee, we provide free samples for defected parts to do replacement except for human damage, under information for your notice
01: KEEPLEADER™ always posts the new technical file in our homepage that can help our client in new technical information of machines' design, character, application, operation, maintenance,
and related, KEEPLEADER™ also welcome our clients feed back the machines' working condition that can get one to one service
02: If the machine you purchased has any defects, please contact sales representative at KEEPLEADER™, we will assign our experienced engineer analyze your case and provide technical support, in case of damaged parts that cannot repair, KEEPLEADER™ will provide a new parts to replace the defect
03: For any replacement and maintenance, KEEPLEADER™ has user manual and training video
04: KEEPLEADER™ can go to oversea for on-site training
05: KEEPLEADER™ can provide electric diagram if in need
BUYING GUIDANCE
01: Choose your correct system
For customers demanding multiple stage ultrasonic cleaning and high efficiency parts drying, KEEPLEADER™ multi-stage consoles provide the same efficient, effective ultrasonic cleaning technology plus the ability to move the items items through additional wash and rise stages, KEEPLEADER™ will design a custom-sized and custom-featured ultrasonic cleaning machine to meet your specific needs
011: heated ultrasonic cleaning
012: heated ultrasonic cleaning + heated rinse
013: heated ultrasonic cleaning + heated ultrasonic rinsing
014: heated ultrasonic cleaning + heated ultrasonic rinsing + hot air drying
015: Inner size of cleaning tank, frame construction, custom color, ultrasonic frequency
02: Choose your tank size
021: the length*Width*depth you wanting
022: advise KEEPLEADER™ the size of your cleaning parts and cleaning efficiency
03: Each system includes:
031: Full insulated stainless steel tanks
032: Exterior power coat finish
033: Digital temperature controls-each tank
034: Digital timer-controlled ultrasonic cleaning
035: Dual stage filtration-cleaning stage
036: Single-stage filtration rinse stage
037: Low-level float sensors-each stage
04: Exceed industry standards
041: All size available, including bench version
042: High quality stainless steel construction
043: For vapor degreasing, cleaning and drying applications
044: Full solution control features
Shenzhen Keepleader Machinnery Co., Ltd. is made-to-order manufacturer, of ultrasonic cleaning machine, ultrasonic welding machine, high frequency welding machine, and various packing machine.
HK KEEPLEADER Ltd have over 30 staffs, 6 engineers in of them, work with sales representative to find a good solution for customized design, since establishing in 2009, the products has already sold to North America, European countries, Asian countries, African countries and Middle East countries, have new model born every month with endless improvement, which lie in the joy of achievement and in the thrill of creative efforts.
Ultrasonic cleaning machine: Single tank ultrasonic cleaning machine and multistage ultrasonic cleaning machine grouped in, ultrasonic golf club cleaner, ultrasonic blind cleaning machine is a practical application for single tank ultrasonic cleaning machine, vapor degrease listed in multistage ultrasonic cleaning machine.
Ultrasonic welding machine: Has ultrasonic plastic welding machine and ultrasonic metal welding machine, portable ultrasonic spot welder, ultrasonic lace sewing machine, CD/DVD sleeve making machine in the group of ultrasonic plastic welding machine, ultrasonic brass tube end sealing machine and battery electrode welding machine in the group of ultrasonic metal welding machine.
High frequency welding machine: High frequency PVC bag forming machine, high frequency tarpaulin welding machine, high frequency canopy, awning, sunshade, sunblind welding machine, high frequency car cover, truck cover welding machine, high frequency Billboard welding machine, high frequency stretch ceiling welding machine, high frequency outdoor tent welding machine, high frequency induction heating machine, high frequency embedding machine, high frequency inflatable products welding machine, and high frequency car pad embossing machine and etc in the lists of this group.
Packing machine: Blister packing machine, vacuum packing machine, skin packing machine.
Please remember renowned brand "keepleader".
