Unbeatable Price/Performance Ratio Rigid Radial Drill Press Machine (ZQ3040C*12)

Name: Unbeatable Price/Performance Ratio Rigid Radial Drill Press Machine (ZQ3040C*12)
Brand: china-manufacturer-directory.com
SKU: 758892765
Availability: InStock
Rating: 4.6 (140 reviews)

Price:	US $ 1/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Features:
With artistic good looking and its general arrangement is very harmonized
With mechanical gear change, convenient to operate.
With comatic automatic ascent and descent cranking bar and production efficiency is high.
With confident construction, high precision and durable in use.

specification	units	ZQ3040C*10	ZQ3040C*12	ZQ3040C*13
Max drilling diameter(steel/cast iron)	mm	35/40	35/40	35/40
Spindle taper		MT.4	MT.4	MT.4
Motor power	kw	3/0.75	3/0.75	3/1.1
Spindle speed and steps	rpm	38-900/8	38-900/8	38-900/8
Spindle feeds	mm/r	0.10,0.15,0.25	0.10,0.15,0.25	0.10,0.15,0.25
Spindle travel	mm	270	270	270
Diameter of the column	mm	230	230	280
Distance from spindle center to column surface	mm	350-1300	350-1200	350-1300
Distance from spindle nose to base surface	mm	130-1100	130-1100	260-1050
Worktable size	mm	495305305	495305305	495305305
T-slots	mm	18/22/9	18/22/9	18/22/9
Base size	cm	15172245	1707224	1768022
Working surface	cm	95*55	114*55	122*66
Base T-slots	mm	18/30/15	18/30/15	18/30/15
Overall dimensions	cm	17072235	19072235	20080240
N.W/G.W	kg	1650/1850	1800/2000	2200/2400
Packing size	cm	17075225	19590225	19595227

Prod Model:	ZQ3040C*12
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max Drilling Diameter:	35mm/40mm
Motoe Power:	3kw/1.1kw
Spindle Travel:	270mm
Worktable Size:	495mm305mm305mm
Structure:	Radial Drilling Machine
Layout:	Vertical
Controlling Mode:	Artificial
Automatic Grade:	Semiautomatic
Precision:	High Precision
Number Of Shaft:	2
