Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,EXW |
Min Order: | 1/Piece |
Pay Type: | T/T,Paypal,Western Union |
Prod Model: | HCS200 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Weight: | 3kg |
Size: | 155(W) × 325(D) × 174.5(H)Mm |
Scan Part: | Duplex |
Sensor: | Cis( Contact Image Sensor) |
Driver: | Twain |
Type: | Data Collector |
Certification: | CE |
Item | Specifications | |||
Available Doc | Height | 54~106mm | ||
Length | 80~235mm | |||
Weight | 60~120g/m2 | |||
Scanner | Scan part | Duplex | ||
Sensor | CIS( Contact Image Sensor) | |||
Resolution | 100/200/400dpi | |||
Color | 8bit Grey, 1bit B/W, 24bit True Color | |||
File Type | TIFF G4, JPEG, BMP | |||
Speed | 90cpm(180ipm) : 200dpi gray 40cpm(80ipm) : 200dpi color | |||
Driver | Twain | |||
Remarks | -Automatically control the thickness/possible to scan card, ID card -Double Feed Detection, Dropout Color -Imprinter, MICR Reader | |||
MICR reader | Code | E13B and CMC7 | ||
Using head | Magnetic head | |||
Interface | USB2.0/USB B Type, RS232C, Ethernet (optional) | |||
Power | Adapter Input | AC 100~240V, 50~60Hz, 1.75A | ||
Adapter Output | DC 24V/1.75A | |||
Consumption | 50w max. | |||
Current | 1.5A max. | |||
Sheet specs | Thickness | 0.09-0.12mm | ||
Length | 80-235mm | |||
Height | 54-108mm | |||
Feeding Docs | Max 100sheets | |||
Light Source | Three color(RGB) / LED | |||
Scan mode | B&W, Gray, 24bit Color | |||
Scan resolution | 200 - 400dpi | |||
Speed | B&W | 80ppm/200dpi, 35ppm/400dpi | ||
Gray | 80ppm/200dpi, 35ppm/400dpi | |||
Color | 25ppm/200dpi, 10ppm/400dpi | |||
Size | 155(W) × 325(D) × 174.5(H)mm / 3.05kg | |||
Environment | Operating | 10~40C /20 ~ 80%RH, non condensation | ||
Storage | -20~70C /5 ~ 95%RH, non condensation |
