Product Specifications
| Prod Model: |
cx |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Experience: |
More 20 Years |
| Exported: |
More 80 Countries |
| Quality: |
World-Class |
| Maintenance: |
Less and Easy |
| Warranty: |
One Year |
| Type: |
Vortex Flow Meter |
| Accuracy: |
>?à1% |
| Measuring Media: |
Liquid |
| Measuring Principle: |
Mechanics |
| Size: |
DN50-100 |
| Main Application: |
Fuel Oil |
Product Description
General Introduction
Intelligent Vortex precession flowmeter developed by our company is a new flow instrument at the leading level in our country. This instrument has a combined function of flow capacity, temperature and pressure measuring. It can also conduct auto compensation of temperature, pressure and compressibility factor. It is an ideal gas dosing instrument for petroleum, chemical, electricity and metallurgic industries.
1.1 Main Features of the Product
L The instrument has no mechanical moving parts, and is incorruptible, stable and reliable. It has a long service-life and requires no special maintenance even after long-time operation.
L It adopts 16 Digit Microcomputer chip with high integration, small volume, good performance and excellent overall functions.
L The intelligent flowmeter has a combination of flow measuring probe, microprocessor, pressure pickup and temperature pickup and adopts internal structuring to make a firm structure. It can directly measure flow capacity, pressure and temperature of the fluid and conduct synchronized compensation and compressibility factor revision.
L It adopts dual detect technique to effectively increase detecting signal intensity and reduce obstruction caused by pipeline vibration.
L It adopts national leading vibration-proof techniques to effectively suppress vibration and undesired signal caused by pressure oscillation.
L It adopts dot matrix display screen of Chinese character to display more significant digits to be Convenient and intuitively read and can directly display flow volume while in operating condition, flow volume, total volume, medium pressure, temperature and such parameters of standard condition.
L It adopts EEPROM technique to make parameter setting more convenient and can be permanently stored. Historical data as long as a year before can be also stored.
L The Converter can deliver frequency pulse, 4~20mA analog signals and has RS485 interface which makes it directly conduct network interconnection with computers and makes delivery distance as long as 1.2km.
L With signal transfer output of several physical parameters, users can choose any of them.
L Gauge head of the flowmeter can rotate by 360 degree, it makes application and installation more convenient.
L it is equipped with data acquisition unit of our company, therefore, data can be distantly delivered by internet or telephone network.
L Pressure and temperature signal are transducer input mode with strong interchangeability.
L The whole machine has a low power consumption; Power can be supplied both by battery and external power source.
| Inside Nominal Diameter(mm) | Type | Rangeof Flow( m3/ h) | Operating Pressure
( MPa) | Accuracy Rating | Repetitiveness |
| 20 |
| 1.2~15 | 1.6
2.5
4.0
6.3
10
16 | 1.0
1.5 | ≤2.5MPa
Aluminium alloy
≥4.0MPa
Stainless steel
Lower than one third of the absolute value of the limit of intrinsic error |
| 25 |
| 2.5~30 |
| 32 |
| 4.5~60 |
| 50 | Type A | 10~150 |
| Type B | 6~75 |
| 80 | Type A | 28~400 |
| Type B | 18~200 |
| 100 | Type A | 50~800 |
| Type B | 40~600 |
| 150 | TypeA | 150~2250 | 1.6
2.5
4.0 |
| Type B | 100~1200 |
| 200 |
| 360~3600 |
Cixi flowmeter Co., Ltd. Was established in 2008 and since then has been dedicating itself to research and manufacture of various kinds of flowmeter. With sophisticated experience in technology and management, CIXI Flowmeter has made a name for itself as an excellent manufacturer of various kinds of flowmeter. In 2007, we have especially set up Shanghai Cixi Instrument Co. Ltd for handling the deals of Export.
Thanks to outstanding performance of products, CIXI Flowmeters are being applied in more and more fields where there' S liquid to measure. Now company involves in polyurethane, fuel consumption, automotive, dispensing robots, semiconductors, odorizing equipment, batteries, electricity, telecommunications, petroleum, chemical, coal, metallurgy, water conservancy, food, medical, machinery and other industries. CIXI Flowmeters have found users in many countries besides China, such as Malaysia, India, Thailand, Vietnam, South Africa and so on. Increasing number of users are finding that CIXI Flowmeter are kind of product with super performance and reasonable price.
Now we have super mirco flow meter, oval gear flow meter, coriolis mass flow meter, electromagnetic flow meter, piston flow meter, and Spur gear flow meter, gear pump, gear metering pump. There is no other manufactures who can produce micro flow meter and many company import this kind of flow meter from Japan or America. After we put our micro flow meter into market, the news was spreaded widely and we got many reputation from our client. We now have sold this flow meter to more than 100 countries which contain wide and different applications. Meanwhile our oval gear flow meter has aquired many certificates and filled the vacancy of Chinese market. At the same time, in order to cooperate with the whole set of sales and services of the product, we can also produce supporting quantitative systems, various proportioning systems and industrial automation systems, allowing customers to have a wider range of choices.
