Product Specifications
| Prod Model: |
W11 series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color:Customized: |
Power: Mechanical |
| Automation: |
Automatic |
| Type For Cutting Machine: |
CNC Cutting Machine |
| Type For Fold-bending Machine: |
CNC Fold-bend Machine |
| Application: |
Medical |
| Type: |
Pipe and Tube Bending Machine |
Product Description
Main characters:
1 All equipments are SIEMENS or SHNEIDER
2 The material is 42Crmo or 45 steel
3 Higher precision for small size plate to roll
Specification
Specification
W11-12*2500
Max thickness of coiled plate: 12mm
Max width of coiled plate: 2500mm
Yielding limit of sheet metal: 245m
Coiling speed: 4m/min
Min full loading diameter of coiled plate: 650mm
Diameter of top sharft: 260mm
Diameter of bottom sharft: 220mm
Central distance between bottom sharfts: 320mm
Motor power: 11kw
Size: 4680*1250*1450mm
Weight: 4800kg
Specification
W11-12*2500
Max thickness of coiled plate: 12mm
Max width of coiled plate: 2500mm
Yielding limit of sheet metal: 245m
Coiling speed: 4m/min
Min full loading diameter of coiled plate: 650mm
Diameter of top sharft: 260mm
Diameter of bottom sharft: 220mm
Central distance between bottom sharfts: 320mm
Motor power: 11kw
Size: 4680*1250*1450mm
Weight: 4800kg
|
Extra Services |
Exported to Countries USA, Australia, Brazil, Saudi Arabia, etc. |
|
Material of the roller: |
42CrMo |
|
Transducer: |
Omron |
|
Control: |
CNC |
|
Pump: |
Gear pump |
|
PLC: |
MITSUBISHI |
|
Operation: |
Touch Screen |
|
Seal parts: |
AILATE |
|
Axletree: |
Wafangdian axletree |
|
System: |
Hydraulic |
|
Seal |
NDK |
Our company is specialized in producing series of industrial sweeper machine, shearing machine, bending machine, rolling machine and plate unrolling leveling shearing production line of "Juli" brand. The products are widely applied to light industry, aviation industry, marine industry, metallurgy, instrument industry, electrical equipment, stainless steel product, construction and decoration industry, etc. The products are exported to Europe, Southeast Asia, the Middle East, etc.
Our company has several top-class experts with professional knowledge in cutting, bending, rolling and plate unrolling leveling shearing production line. The quality and technology are ranked as the first class in this field. Our company is constantly developing the leading-edge products with advanced consciousness, new concept, innovation and the overseas technology, which will lay the solid foundation for "Juli" to be a famous brand in the world in machine tool industry. All the staff members are devoted themselves to serving the company with meticulous professional dedication and solidarity. We are sincerely looking forward to cooperating with friends all over the world to create greater success.
Welcome you to visit at any time.
