| Supplier: | Dongguan Riotouch Technology Co., Ltd. |
|---|---|
| Price: | US $ 559-729/Piece |
| Min Order: | 1/Piece |
| Quantity:: | |
| Trade Terms: | FOB,CIF,CIP |
|
|
| Prod Model: | GT65 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: | 50" ,55",65",70",84" |
| Visual Angle: | 178 |
| Contrast: | 1600:1 |
| Interface Type: | Serial, USB, HDMI,Composite Video |
| System Support: | Android/Win7/Win8/Linux |
| Touch Points: | 2 Points, 10 Points Touch |
| Screen Size: | 50-60 Inches |
| Aspect Ratio: | 4:3 |
| Application: | Education and Training System |
| Screen Type: | Infrared |
| Customized: | Non-Customized |
| Resistive Touch Screen Type: | Infrared |
| Model | GT65 | ||||||
| Image | |||||||
| LED | LED panel size | 65 inch | |||||
| LED brand | CHIMEI (CMO) | ||||||
| Packing Parameters | Enternal Size | 1503*882.8*75.7mm (Without base) | |||||
| Touch Size | 1428*807.7mm | ||||||
| Net Weight | 50KG | ||||||
| Gross Weight | 70KG | ||||||
| Package size | |||||||
| Package size with wooden box | |||||||
| Power Parameters | Power: | <160W | |||||
| Standard Power | <0.73W | ||||||
| Display Parameters | Active Display Area | 1428.48 (H) x 806.1 (V)mm | |||||
| 0.630(h)x0.630(v)mm | |||||||
| Display Colors | 1.07 billion colors | ||||||
| Contrast | 1600:1 | ||||||
| Resolution | 1920x1080pixel | ||||||
| Brightness | 300cd/m2 | ||||||
| Viewing Angle | 176 degree | ||||||
| TV Parameters | TV Standard | NTSC M/N,PAL BG/DK/I/H,SECAM L/L | |||||
| Multimedia Formats | MPEG1,MPEG2,MPEG4,H264,RM,RMVB,MOV, | ||||||
| USB2.0 Multimedia Playback | Vido/Audio/Picture | ||||||
| USB System Upgrading Online | Support USB online upgrading function | ||||||
| Resolution | Max. 1080P format | ||||||
| HDMI | V1.3, 720P/1080P | ||||||
| HDCP | V1.1 | ||||||
| Scanning Format | Support 1080i Video crisscross DAS (Dynamic Adaptive Scan ) | ||||||
| Sound Control | Automatic sound standard detection, support for balance adjustment and surround Sound | ||||||
| Sound Output | 2X10W | ||||||
| Input and output ports | HDMI Input port | 2-line (HDMI1 keep for Inside OPS) | |||||
| VGA Input port | 1 Line | ||||||
| PC Audio port | 1 Line | ||||||
| Headphone/Audio output | 1 Line | ||||||
| AV Input port | 1 Line | ||||||
| Y/pb/cb/pr/cr inport | 1 Line | ||||||
| RF input ports | 1 Line | ||||||
| USB Multimedia Input ports | 1 Line | ||||||
| Touch parameters | Touch Technology | Infrared touch technology | |||||
| Touch mode | Single, multipoint,Mouse click | ||||||
| Inductive objects | Finger, pen or any other opaque objects | ||||||
| Inductive size | Diameter≥5mm | ||||||
| Resolution | 32767*32767 | ||||||
| Response time | 1) First dot(click):8ms, continuously(writing):3ms 2) multipoint click:firstdot(click):8ms,continuously(writing):8ms 3) Mouse click:first dot(click):8ms,continuously(writing):8ms | ||||||
| Cursor speed | UP to 300 dots/s Multipoint,mouse click:125 dot/s | ||||||
| Operating life | ≥60,000,000 times to click | ||||||
| Power | USB power supply (4.6-5V, DC) | ||||||
| Power consumption | ≤1w | ||||||
| Operation Systerm | Windows 8, windows 7, XP, Mac, Linux, Android | ||||||
| Calibration | HID devices standard, accord with Win7 multi-touch protocol, no need special software to calibrate, just use Table PC setting to finish the calibration. | ||||||
| Anti-light decay function | Anti-light decay circuits to prevent the performance degradation caused by long working hours | ||||||
| LED Test Software | Supply touch screen LED test software to test the function of each couple of the LED lights and the drawing functions | ||||||
| Antilight interference function | can work properly in direct sunlight condition | ||||||
| Standard Accessories without PC | Remote Control | TV Remote control | |||||
| Power cable | 1.5m | ||||||
| HDMI cable | 1.5m (without PC) | ||||||
| VGA Input port | 1.5m (without PC) | ||||||
| USB | 5M cable (Without PC) | ||||||
| Audio Cable | 1.5m | ||||||
| CD | 1 PCS | ||||||
| Pen without ink | 2 PCS | ||||||
| Warranty Card | 1 Pcs | ||||||
| User manul | 1 PCS | ||||||
| Wall brackets | Screws, wall mount kits | ||||||
Standard Accessories without PC | Remote Control | TV Remote control | |||||
| USB cable | 1.5m USB cable for touch monitor, USB2.0 | ||||||
| VGA cable | 1.5m VGA cable | ||||||
| Audio cable | 1.5m audio cable | ||||||
| CD | 1 pcs | ||||||
| Pens without ink | 2 pcs | ||||||
| Teaching Pointer | 1 pcs | ||||||
| User manul | 1 pcs | ||||||
| Wall brackets | Screws, wall mount kits | ||||||
| Standard Accessories with PC | Remote Control | TV Remote control | |||||
| CD | 1 pcs | ||||||
| Pens without ink | 2 pcs | ||||||
| User manul | 1 pcs | ||||||
| Teaching pointer | 1 pcs | ||||||
| Wall brackets | Screws, wall mount kits | ||||||
| Motherboard | Intel Hm77 | ||||||
| CPU | Intel i5-3337U | ||||||
| RAM | DDR II 4G | ||||||
| Hard Disk | 500G | ||||||
