General Specification
Tunnels Size: 650W*500H mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 170kg
Dose per Inspection<1.4μGy Resolution 38AWG guaranteed 40AWG typical. Spatial resolution: Level: dia1.0mm, Vertical: dia1.0 mm Penetrate resolution: 32 AWG Penetration:38mm Steel Guaranteed, 40mm typical.
X-ray Leakage <0.65 μGy/h at a distance of 5mm from external housing
Gray level: 1mm to 60mm aluminum step
Organic level: 1mm to 120mm Poly methyl methacrylate (Orange color)
Inorganic level: 0.1mm to 12mm steel (blue color)
Mixture level: 1mm to 60mm aluminum (Green color)
Material distinguishes: PVC in green, Nylon 6 in orange.
Film Safety: Guarantee ISO1600 Film
Image System
X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
Image Processing: Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval.
Image Grey Level: 4096
Image Max Resolution: 1024 * 1280 pixel
Image Processing: 24bit for processing real time
Image storage: Storage 60000 pictures in real time
Zoom: 2,4,8,16 Times Enlarge, Whole screen continuous observation
Multi-energetic distinguish objects: organic objects in orange, inorganic objects in blue, mixture in green
High-energy/low energy : switch from high energy to low energy
Assist to detect explosive powder
Hardware
Roller engine (China brand: INTEROLL )
Computer: Brand GRANTECH.
Intel G41 ATX board, VGA/DVI-D/2*INTEL GIGA_LAN/AUDIO, SUPOORT P4, CORE 2, CORE 4, Seagate 3.5'' 500G, ST3500418AS 7200, 16M SATAII, E3400 CORE 2, 2.6g 45nm, 1MHZ L2 CAHE, FSB 800MHz, 2G, Kingstong DDR3 1333MHz 240PIN Detector Brand: HAMAMATSU or DT
Monitor: High Resolution Color, LCD Philippe, 17inch
X-ray Generator (China brand: SPELLMAN)
Generate direct: Downward
Generate anger: 82 degree
Anode Voltage: 160Kv
Anode power: 0.4 to 1.2mA
Cooling / Duty Cycle: Oil Cooling /100%
Remarks: 1mR/hr=8.7μGy/hr 1mR/hr=10μ Sv/hrL
Shenzhen Security Electronic Equipment Co., Ltd (SEE), is a high-tech company integrating R&D, manufacturing, engineering, training and services.
SEE gradually establishes a very comprehensive product range covering X-ray machines with different tunnel size X-ray machines, Walk through Metal Detector, Hand-held Metal Detector, Liquid Scanner, Explosive auto detection system, under vehicle system and etc. SEE security systems have been used in different countries and regions in airports, seaports, customs, railway stations, long-distance bus stations, jail houses, courts yard, and many other security-related applications.
With ISO9001 management system, SEE always keeps running with high efficiency by balancing development on her product R&D, manufacturing, quality control and service according to ISO strict international standard requirements.
With global marketing strategy, SEE provides innovative and dependable security solutions to our global customers and makes every effort to continually exceed our customers' Expectations. SEE registered its own trade mark SECUSCAN, which are well known in national market.
SEE is great help for public security solution.
