Product Specifications
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: |
According to The Demand of The Customer |
Processing Type: |
Metal |
Usage: |
General |
Precision: |
Precision |
Automatic Grade: |
Semiautomatic |
Object: |
Metal |
Type: |
Turret Milling Machine |
Structure: |
Vertidal |
Controlling Mode: |
Normal |
Product Description
Spindle taper: ISO 40
Spindle travel: 150mm
Distance from spindle to column: 200~600mm(V)
Distance from spindle to table
155~455mm(V)
0~300mm(H)
Range fo spindle speed
20step 76~6980rpm(V)
12step 60~1350rpm(H)
Size lf table surface: 1250× 320mm
Table travel(X\Y\Z): 800× 300× 300mm
T-slot (number-width-distance): 3/14mm/70mm
Main motor power: 3.7KW(V); 2KW(H)
Overall dimension: 1820× 1520× 2270mm
N\W\/G\W\: 1850/2050kg
Our company is special in producing milling machine, radial arm milling machine and multi-function turret milling machine which are popular in Europe, Southeast Asia market. With high quality, good credit, concentrate all for customer. We are obey the principle to satisfy with our customer by actively innovating, absorb other companies' advantage, perfecting every product, moves customers with good credit, wins customers with high quality. We will perfect our service with higher, faster, newer, stricter woking attitude, and afford our efforts for your success.
