Tengzhou Sanzhong Machinery Manufacture Co., Ltd. >> China High Precision Universal Vertical Turret Milling Machine Xq6226A with CE Standard

China High Precision Universal Vertical Turret Milling Machine Xq6226A with CE Standard

Name: China High Precision Universal Vertical Turret Milling Machine Xq6226A with CE Standard
Brand: china-manufacturer-directory.com
SKU: 685669682
Availability: InStock
Rating: 4.4 (66 reviews)

Supplier:	Tengzhou Sanzhong Machinery Manufacture Co., Ltd.
Price:	US $ 1-5000set
Min Order:	1set
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	XQ6226A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Colour:	According to Customer Requirment
Processing Type:	Vertical Milling Machine
Workpiece And Weight:	Large Machine Tool
Original:	Made in China
Automatic Grade:	Semiautomatic
Precision:	High Precision
Controlling Mode:	Artificial
Object:	Tool
Type:	Tool Milling Machine
Structure:	Desktop

Product Description

Brief introduction

1. Universal milling head, machining flexibility
2. Three axis hardening treatment
3. Mechanical feeding device

Specifications	XQ6226A	XQ6226-1
Max.end milling width	125mm	125mm
Max.vertical milling dia.	25mm	28mm
Spindle to table	80-500mm	80-500mm
Spindle speed range	40-1600r.p.m	40-1600r.p.m
Head swivel angle	360°	360°
Table size	1120× 260mm	1120× 260mm
Table travel	600× 270mm	600× 300mm
Overall dimensions	1655× 1500 × 1730mm	1655× 1325 × 1730mm
Main motor power	2.2kw	2.2kw
N.W/G.W	1400/1600kg	1360/1540kg

Our company is special in producing milling machine, radial arm milling machine and multi-function turret milling machine which are popular in Europe, Southeast Asia market. With high quality, good credit, concentrate all for customer. We are obey the principle to satisfy with our customer by actively innovating, absorb other companies' advantage, perfecting every product, moves customers with good credit, wins customers with high quality. We will perfect our service with higher, faster, newer, stricter woking attitude, and afford our efforts for your success.
