Product Specifications
| Prod Model: |
XK-DE1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
1. Fundamental Logic experimental board
2. Electronic technology training box
3. Vocational school teach
1. Main function
Basic Experiment and Training board based on digital technology
2. Main parameters
The power supply: DC +5V
Total capacity: ≤ 5W
Size: 280 * 200 * 32(mm)
Power supply module of this board provides the interface for VCC (+5V) and GND.
This board provides 8 LED lights
This board provides 8 logical switches
This board provides a 1-way adjustable pulse output signal
This board provides two 16P, two 14P, and one 20P locking seat
This board provides two-digit Nixie tube display circuit
This board provides a complete 8-way Responder experiment principle circuit
This board provides a expansion board position of size 109.2mm*90.9mm
Main functions
1. Basic gate circuit
2. Combinational logic circuits (based on the SSI)
3. Encoder and decoder
4. Data selector and data comparator
5. Trigger
6. Counter
7. Register
8.555 Time base circuit
9.8-way responder
