Product Specifications
| Prod Model: |
Various |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Vibrating Screen |
| Application: |
Cement, Magnesium, Limestone, Dressing, Ceramsite |
| Certificate: |
ISO9001,ISO14000 |
| Screen Number: |
1-4 |
| Screen Area (M2): |
2.88-18 |
| Capacity: |
20-900 (M3/H) |
| Installation: |
Under Our Engineer's Guide |
| After Sale Service: |
We Offer |
| Spare Parts: |
We Offer |
| Experience: |
More Than 50 Years |
Product Description
The vibrating screen is machinery and equipment of vibration screening, which is suitable for damp fine grade of difficult materials with dry vibration screening, and is also equipment to process difficult materials of the domestic. Vibrating screen has the process characteristics of large amplitude, large vibration intensity, low frequency and elastic screen surface. In the working process, it maintains the largest rate of hole, which is of high efficiency, large capacity, convenient replacement of sieve plate, and reduces the cost.
YK Series Circular Vibrating Screen:
YK Series Circular Vibrating Screen adopts German technology, and is specially designed to sieve different sizes of aggregate. It is also applied in coal dressing, ore dressing, building material, electricity and chemical industries.
Features and Benefits:
1. High vibrating force with unique eccentric structure. Adopt advanced construction, making the vibrating force powerful.
2. The beam and case of the screen are connected with high strength bolts without welding.
3. Simple structure, easy to repair.
4. Adopt tire coupling and soft connection makes operation smooth.
5. High efficiency, easy maintenance, sturdy and durable.
YK series circular vibrating screen is a single shaft, circular motion inertia vibrating screen, circular vibrating screen is the inertia of the motor work, inertia force of the eccentric block to produce forced vibration screen box, which added to the screen on the surface of the material throwing motion, so that the material particles through the sieve hole of a certain size, realize the screening operation. The vibration exciter is arranged above the gravity of a screen box, the screen box ends of major axis of the ellipse into eight shaped, and the upper end of the major axis of the ellipse to feed the discharging direction, a material quickly disperse to give to the box on the machine, and the discharging end of major axis of the ellipse is against the discharging direction, reduce material movement speed, for difficult to screen material through the screen, and the screen surface circular arc and increase the effective area of screen machine, which can improve its capacity.
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://www.inczk.com/ & http://www.zkcomp.com/
24-hour Free Sales Consulting Phone: 861-0371 -5590 2866.
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Price of rotary kiln: http://www.zkcomp.com/calcining/558. Html
Rotary Kiln: http://www.inczk.com/Products/459. Html
Preheater: http://www.zkcomp.com/calcining/605. Html
Cement Mill: http://www.inczk.com/Products/460. Html
Rotary Dryer: http://www.zkcomp.com/calcining/564. Html
Raw Mill: http://www.inczk.com/Products/1373. Html
Ball Mill: http://www.zkcomp.com/grinding/582. Html
| Model | Screen
layer | deck
size
(m³ ) | Vibration
frequency
(r/min) | Double-
Amplitude
(mm) | Capacity
(m³ /h) | Motor
power
(kw) | Overall
dimensions
(L*W*H)( mm) |
| 2YK1224 | 2 | 2.88 | 970 | 6-8 | 20-120 | 5.5 | 2637× 2382 × 2027 |
| YK1235 | 1 | 4.2 | 970 | 6-8 | 20-150 | 5.5 | 3710× 2464 × 1450 |
| 2YK1235 | 2 | 4.2 | 970 | 6-8 | 20-150 | 7.5 | 3705× 2393 × 2339 |
| 3YK1235 | 3 | 4.2 | 970 | 6-8 | 20-150 | 7.5 | 3621× 2521 × 2830 |
| 4YK1235 | 4 | 4.2 | 970 | 6-8 | 20-150 | 11 | 3510× 2521 × 2581 |
| YK1545 | 1 | 6.75 | 970 | 6-8 | 20-150 | 11 | 4904× 3044 × 2179 |
| 2YK2475 | 2 | 18 | 970 | 6-8 | 120-900 | 30 | 7812× 4308 × 4642 |
| 3YK2475 | 3 | 18 | 970 | 6-8 | 120-900 | 37 | 7718× 4393 × 5033 |
| 4YK2475 | 4 | 18 | 970 | 6-8 | 120-900 | 45 | 7718× 4494 × 5361 |
| YK3060 | 1 | 18 | 970 | 6-8 | 200-900 | 30 | 6207× 4943 × 3108 |
| 2YK3060 | 2 | 18 | 970 | 6-8 | 200-900 | 37 | 6207× 4943 × 3985 |
| 3YK3060 | 3 | 18 | 970 | 6-8 | 200-900 | 45 | 6207× 4943 × 4485 |
| 4YK3060 | 4 | 18 | 970 | 6-8 | 200-900 | 45 | 6207× 4943 × 4785 |
