Product Specifications
| Prod Model: |
HPZS-1011 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Mid East,Eastern Asia,Western Europe |
| Name: |
Zinc 10% or 5% Galvanized Wire Netting |
| Technique: |
Zinc 5%- Aluminum-Mischmetal Alloy-Coated |
| Color: |
Sliver Green Blue etc |
| Technique Standard: |
SGS ISO9001 : 2000 BV etc |
| Lead Time: |
25days After Receive The Balance |
| Port: |
China / According to Client Requirmen |
| Packing Detail: |
Customer's Requirement Acceptable |
| Type Of Company: |
Factory |
| Hole Shape: |
Hexagonal |
| Application: |
Construction Wire Mesh |
| Material: |
Low-Carbon Iron Wire |
| Surface Treatment: |
PVC Coated |
Product Description
ZINC 10% Or 5% Galvanized Wire Netting
Specifications:
1. Material: High quality medium and high carbon steel wire rod
2. Carbon Content: 0.42%-0.90%
3. Tensile Strength: 1100MPA-2000MPA
4. Size: 0.5mm-5.0mm
5. Surface Treatment: Electric galvanized and hot-dipped galvanized
6. Zinc Content: 20g/m2-200g/m2
7. Surface Appearance: Smooth and bright
Applications:
* Water and soil protection
* Bridge protection
* Strengthening structure of soil
* Protection engineering of seaside area
* Control and guide of water or flood
* Flood bank or guiding bank
* Preventing of rock breaking
Advantage:
Galfan offers a more homogenous, ductile and smoother coating than does galvanized zinc. The result is
That the galfan is less affected by abrasion.
Galfan coating offers up to 3 times better corrosion protection than standard zinc coating in salt spray test,
And up to 2 times better corrosion protection than standard zinc coating in the SO2 Atmosphere test.
Galfan offers better sacrificial protection of the steel wire than standard galvanized zinc.
Gabion galfan use the same wire diameters as the galvanized gabions. This is an advantage in corrosive
Environments that have a reduced steel wire diameter as compared to other similar products. The result
Is a better corrosion protection coating than the galvanized zinc or the PVC coated.
It is recommended that galfan coating be utilized when corrosion is the predominant factor for
Determining the expected life span of the mesh structure.
| Hexagonal Gabion Box |
| Model | Opening(mm) | Body wire(mm) | Edge wire(mm) | Lacing wire(mm) | Size(m) |
| DL60 | 60X80 | 2.0-2.8 | 3.0-4.0 | 2.0-2.2 |
2mx1mx0.5m;
2mx1mx1m;
3mx1mx1m;
4mx1mx1m;
4mx1mx0.5m
|
| DL80 | 80X100 | 2.0-3.0 | 3.0-4.0 | 2.0-2.2 |
| DL80W | 80X120 | 2.0-3.0 | 3.0-4.0 | 2.0-2.2 |
| DL100 | 100X120 | 2.0-3.0 | 3.0-4.0 | 2.0-2.2 |
| WL100W | 100X150 | 2.0-3.0 | 3.0-4.0 | 2.0-2.2 |
| DL120 | 120X150 | 2.0-3.0 | 3.0-4.0 | 2.0-2.2 |
Hebei Gabion Hardware Wire Mesh Co., Ltd the registered capital of 38 million yuan. It is located in Asia's largest wire mesh production base Anping, which is located in a major traffic area. Our company is a comprehensive enterprise integrating production, domestic sales, foreign trade, and import and export.
Hebei Gabion Hardware Wire Mesh Co., Ltd has the most advanced welding and woven equipment, strong technical force, scientific process, perfect quality inspection system and adopts ISO9001: 2000 and SGS quality management system. Our products undergo strict quality control, and are certified as quality and reliable products. We mainly produce Temporary fence panel, Gabion and mattress, Mesh fence panel, Steel bar grating, Reinforcing wire mesh, Welded wire mesh, Field fence, Barbed wire, Expanded metal mesh, Perforated metal mesh etc. Our company can make metal mesh of variety of specifications at the customer's requirements. We had established trade partnership with the U. S. A, Russia, Germany, Southeast Asia and other counties and regions, achieved a good reputation in the international market.
Companies adhere to the "science and technology as the cornerstone, depending on the quality as life, efficiency create excellence, reputation for purpose" business philosophy, is committed to provide you with the fastest, most convenient, the most sincere, the most intimate customer service.
Business Type: Manufacturer/Factory
Number of Employees: 217
Management System Certification: ISO 9001,ISO 14001
International Commercial Terms: FOB, CIF, CFR
Terms of Payment: LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Average Lead Time: Peak season lead time: within 15 workdaysOff season lead time: within 15 workdays
Number of Foreign Trading Staff: 11~20 People
Export Year: 2003-09-19
Export Percentage: 41%~50%
Annual Export Revenue: 1.18 Million USD
Main Markets: Southeast Asia/ Mideast
Export Mode: Have Own Export License
Factory Address: No. 38 of Zhenggang Road, Raoyang County, Hengshui, Hebei, China
R&D Capacity: Own Brand(GABION)
No. of R&D Staff: 5-10 People
No. of Production Lines: 8
Annual Output Value: US$10 Million - US$50 Million
