Product Specifications
| Prod Model: |
KMY8707B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension: |
H520xw500xd283 |
| Monitor Size: |
15", 17", 19" or Above Touch Screen |
| Touch Screen: |
Saw Touch or IR Touch or Upon Clients |
| Supported OS: |
Win7 or Win8 (Test Version) |
Product Description
Desktop Self Payment Kiosk with Printer, POS Terminal Kiosk
KMY 8700 Series Kiosk Basic Configuration
Components Specification
Computer Industrial Host:
Mother Board: Industrial POS-1711VNA(Intel845)
CPU: Intel P4 3.0G (upgradeable as option)
RAM: 1GB(upgradeable as option)
HardDisk: 80 G (upgradeable as option)
(More sizes and types of PC available upon request)
Monitor
TFT LCD: 15, 17 or 19 optional
: Brightness 300~1200nits
: Contrast 450: 1~1000: 1
Resolution:
15 1024*768
17 1280*1024
19 1280*1024
More sizes between 20"~46" upon request
Touchscreen:
SAW Touch: 15 17 19"
Resolution 4096*4096
(More types of touchscreen available: Capacitive, resistive or IR optional)
Input Device: 3DES Metal EPP: 16 keys, waterproof, dustproof, vandal proof
Metal Keyboard: 64 keys, waterproof, dustproof, vandal proof
Card Reader: Motorized/Dip: Magcard/IC reader; Shutter(motorized); Confiscate card(motorized)
Printe: Thermal Printer: Width 80mm; Black mark sensor; Full/half cutter
DOT Matrix: Width 80mm; Black mark sensor; Full/half cutter
Speaker: Multimedia: Left-right bi-channel amplified output
Enclosure ColdRoll Steel:
Steel powdercoated front
Powercoated backcover
OS&Drivers: Windows XP+SP2 (WINCE, Linux, UNIX, WIN2000) and all related drivers available
Packing: Bubble Foam, carton, wooden case
Other Optionals: UPS, Video Camera, Alarm System, Barcode Scanner, Track Ball, Photo Printer, Cash Acceptor, Card Dispenser, Check Acceptor, Infrared, Bluetooth, PSAM Card, etc.
KMY8700 series kiosks are also called Mini Desktop Kiosks which are designed for the applications that need diversified functions within limited space and budget. They are easy to move and easy to operate, applying for banking systems, retail counter, hotel counter, photo printing, etc.
The kiosks can be used as public internet access, information check, music download, order entry, and many others in Retail, Hotels, Finance, Banking and Insurance, Gaming & Gambling, Travel and Tourism, Queue, etc.
