Feature Descriptions:
Various sizes from7"--46" such as: 7", 8", 10.4", 12.1". 15", 17", 18", 19", 20", 21.5", 22", 24"26"32"37"40"42"46"
1. Intel N2600
2.16GB high speed solid state disk (optional)
3. Fanless design for less noise
4. Sumsang panel, High configuration, vibration proof
5. Wide temperature and humidity
6. Open Frame touch( or industrial panel PC with aluminum bezel optional)
7. Any customized service
8. CE, RoHS, FCC, CCC certificates.
9. For medical panel PC, marine panel PC, for information display, embedded in industrial automatic device
Specification |
| Item | Project | Parameter |
| LCD Display | Display Type/Size | Color TFT LCD/15″ |
| Active Display Area (mm) | 304.128mm(W)×228.096mm(H) |
| Display Mode | 4:3 |
| Max Resolution | 1024×768 |
| Support Color | 16.7M |
| Luminance(cd/m2) | 350nit |
| Backlight | LED backlight |
| Contrast Ratio | 700:1 |
| Response Time | 4ms |
| Pixel Pitch | 0.297(H)×0.297(V) |
| Viewing Angle | 140/125(H/V) |
| Processor System | Chip set | Intel NM10 |
| CPU | Intel N2600 |
| Internal memory | DDR3 (800/1066/1333MHz) Typ. 2G (Max 4G)(optional) |
| Hard disk | 16GB high speed solid state hard disk (optional) |
| HDMI ports | 1xHDMI Port |
| COM ports | Defaultx2 COM(optional) |
| Ethernet ports | Two Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.) |
| Audio | with Realtek ALC662
Line-In/Line-Out/Speaker out with 3W AMP Circuit |
| USB ports | Defaultx4 USB(Max x6) |
| Touch Type(optional) | TouchScreen Type | Resistive(4-wire/5-wire) |
| Optional Touch Type | SAW, IR, Capacitive |
| TouchScreen interface | USB or Serial (RS232) |
| Power supply | Input Voltage | DC12V 3A |
| Output Rating | less than 25W |
| Temperature Range | Operating Temperature | -20~70ºC |
| Storage Temperature | -20~70ºC |
| Relative Humidity | 20(%RH)~90(%RH) |
Auka Industrial Limited is a high-tech enterprise specializing in TFT LCD Monitor, Touch Screen Monitor, Camera Field Monitor, Embedded Computer, Industrial Panel PC, CCTV Monitor, USB Touch Monitor, Open Frame Monitor, LCD SKD Module, All in one POS, Transparent LCD, Sunlight Readable Monitor, FPV Monitor, Police Body Worn Camera and car DVR Recorder. And are widely used in the fields of security monitoring, traffic control center, broadcasting system, military, city square, shopping mall, bank, school and hospital, etc. Our monitors can be applied in devices like ATM, Self-service kiosk, Transportation, Automatic Vending Machine, Gaming Machine, POS, Medical Treatment, CNC Machine etc. We have set up a large customer network and gained praise since establishment in 2005 for preciseness, cordiality, powerful technology support and perfect market understanding. A factory with more than 8, 000 sq. M. As well as a team of well-trained employees. Our department of R&D, production, sales and after-service strictly abide by ISO9001 quality control system. Certified by CE, FCC, RoHS, CCC and E-MARK standard, the performance of our products meets or exceeds the advanced world standard. And our own-designed LCD Touch Monitor have became popular among many long- term customers and partners. Our products have been exported to America, Europe, Middle East, Australia and Southeast Asia.
