Supplier: | Xiamen Topway Machinery Co., Ltd. |
---|---|
Price: | US $ 65000/Piece |
Min Order: | 1UNIT |
Quantity:: | |
Trade Terms: | FOB,CFR,CIF |
![]() |
Prod Model: | D6 |
---|---|
Markets: | South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
Track Bulldozer Engine: | Cummins |
Track Bulldozer Operating Weight: | 16500kgs |
Track Bulldozer Hydraulic Parts: | High Quality |
Walking Mode: | Crawler |
Certification: | ISO9001: 2000 |
Condition: | New |
Type: | Bulldozer |
Scraper Type: | Bulldozer |
Load And Unload Method: | Dozer |
Technical Data\Model | TMD6 | |||
Dozer | Tilt | |||
Operating weight with ripper (kg) | 16500 | |||
Ground pressure (kpa) | 55.23 | |||
Track gauge (mm) | 1880 | |||
Min. ground clearance (mm) | 445 | |||
Gradient | 30°/25° | |||
Dozing capacity (m³) | 4.5 | |||
Blade width (mm) | 3297 | |||
Max. digging depth(mm) | 592 | |||
Overall dimentions with ripper(mm) | 5037*3297*3077 | |||
Engine | Type | SHANGCHAI C6121 | ||
Rated revelution (rpm) | 1900 | |||
Flywheel power (KW/HP) | 119/162 | |||
Driving system | Torque converter | Outside separating combination | ||
Transmission | Planetary, power shifting transmission with three speeds forward and three speeds reverse, speed and direction can be quickly shifted | |||
Steering clutch | Multiple-disc oil power metallurgy disc compressed by spring. hydraulic operated. | |||
Brake clutch | Brake is oil two direction floating band brake operated by mechanical foot pedal. | |||
Final drive | The final drive are double reduction with spur gear and segment sprocket, which are sealed by duo-cone seal, easy to maintanence | |||
Undercarriage system | Type | Swing type of sprayed beam, Suspended structure of equalizer bar | ||
Number of track rollers (each side) | 7 | |||
Pitch (mm) | 203 | |||
Width of shoe (mm) | 560 | |||
Gear | 1st | 2nd | 3rd | |
Forward km/h | 0-4.0 | 0-6.9 | 0-10.9 | |
Backward km/h | 0-4.8 | 0-8.4 | 0-12.9 | |
Implement hydraulic system | Max. system pressure (Mpa) | 15.5 | ||
Pump type | Gears pump | |||
System output (L/min) | 178 |
