Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,EXW |
Min Order: | 1/Piece |
Pay Type: | L/C,T/T,Western Union |
1. Intel N2600+NM10 fanless pc
2.16GB high speed solid state disk (optional)
3. Sumsang panel,High configuration,vibration proof
4.wide temperature and humidity
5. Open Frame touch( or industrial panel PC with aluminum bezel optional)
6. Any customized service
7.CE, RoHS, FCC, CCC certificates.
8. for medical panel PC, marine panel PC, for information display, embedded in industrial automatic device
Specifications | ||||||
Item | Project | parameter | ||||
LCD Display | Display Type/Size | Color TFT LCD/19″ | ||||
Active Display Area (mm) | 376.32mm(W)×301.056mm(H) | |||||
Display Mode | 4:3 | |||||
Max Resolution | 1280×1024 | |||||
Support Color | 16.7M | |||||
Luminance(cd/m2) | 250cd/M2 | |||||
Backlight | CCFL | |||||
Contrast Ratio | 1000:1 | |||||
Response Time | 5ms | |||||
Pixel Pitch | 0.294(H)×0.294(V) | |||||
Viewing Angle | 170/170(H/V) | |||||
Processor System | Chip set | Intel N2600+NM10 | ||||
CPU | N2600 | |||||
Video | Intel GMA3650,640MHz | |||||
Internal memory | DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional) | |||||
Hard disk | 16GB high speed solid state disk (optional) | |||||
HDMI ports | 1xHDMI Ports | |||||
COM ports | Defaultx2 COM(optional) | |||||
Ethernet ports | 2xRJ45 Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.) | |||||
Audio | Realtek HD ALC269Q Line-In/Line-Out/Speaker out with 1W AMP Circuit | |||||
Touch Type | USB ports | Defaultx4 USB(Max x6) | ||||
TouchScreen Type | Resistive(5-wire) | |||||
Power supply | TouchScreen interface | Serial (RS232) or USB | ||||
Input Voltage | DC12V 4A | |||||
Temperature Range | Output Rating | <=35W | ||||
Operating Temperature | -20~60ºC | |||||
Relative Humidity | 20(%RH)~90(%RH) |
Prod Model: | PC-1901T |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Display Mode: | 4:3 |
Resolution: | 1280X1024 |
Brightness: | 250CD/M2 |
Backlight: | CCFL |
Contrast Ratio: | 1000:1 |
Chipset: | Intel N2600+Nm10 |
Memory: | 2 GB |
Hard Disk: | 16 GB |
Type: | IPC |
Screen Size: | 16-20'' |
Touch Screen: | Touch Screen |
Installation: | Wall-Mounted |
Application: | Industrial |
Power Supply Type: | ATX12V |
Accessories: | Industrial Power Supply |
CPU Type: | N2807 |
