Product Specifications
| Prod Model: |
MS8238C |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Grade: |
Professional |
| LCD Display: |
2000 Counts |
| Diode: |
2.7V |
| Display Mode: |
Digital |
| Power Source: |
AC and DC |
| Theory: |
Electronic Meter |
| Installation: |
Portable |
Product Description
2000 Counts Professional Digital Multimeter MS8238C:
The MS8238C is a small, safe and reliable 3 1/2 digital handheld autoranging multimeter.
This meter can measure AC/DC voltage, AC/DC current, resistance, capacitance, diode, continuity,
Battery test, temperature and non-contact voltage test. This tool is ideal for professionals and hobbyists
Alike.
Features of Digital Multimeter MS8238C:
* Test voltage, current, resistance and temperature
* Diode check and continuity test
* Data hold
* NCV(Non-contact AC voltage)
* Battery measurement
Specifications of Digital Multimeter MS8238C:
* DC voltage
- Range: 200mV/2V/20V/200V; Accuracy: +/-(0.5%+2)
- Range: 600V; Accuracy: +/-(0.8%+5)
* AC voltage
- Range: 2V/20V/200V; Accuracy: +/-(0.5%+5)
- Range: 600V; Accuracy: +/-(1.0%+5)
* DC current
- Range: 200μ A/2mA/20mA/200mA; Accuracy: +/-(0.8%+3)
- Range: 10A; Accuracy: +/-(1.0%+3)
* AC current
- Range: 200μ A/2mA/20mA/200mA; Accuracy: +/-(1.0%+3)
- Range: 10A; Accuracy: +/-(1.5%+10)
* Resistance
- Range: 200Ω /2KΩ /20KΩ /200KΩ /2MΩ ; Accuracy: +/-(0.8%+4)
- Range: 200MΩ ; Accuracy: +/-(1.0%+4)
* Temperature(° C/° F)
- Range: -20° C~750° C; Accuracy: +/-(1.0%+4)
- Range: -4° F~1382° F; Accuracy: +/-(1.0%+4)
* Display: 2000 counts
* Diode: 2.7V
* Continuity Buzzer: <30Ω
* Data hold
* DCV: Non-contact AC voltage
* Battery measurement: 12V/9V/1.5V
* Power supply: 1x9V 6F22 1604 Battery
* Product size: 188mm * 93mm * 50mm / 7.4" x 3.7" x 1.9"
* Product weight: 380g/0.81lb
* Safety rating: CE ETL RoHS CAT III 600V
