Product Specifications
| Prod Model: |
PS-200-840M |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Preform Injection |
| Automation: |
Automatic |
| Structure: |
Horizontal |
| Computerized: |
Computerized |
| Plastic Type: |
Thermosetting |
| Plasticizing Way: |
Plunger Type |
| Certification: |
ISO9001:2008 |
Product Description
Guarantee : 1 year.
Installation:
We can send technician to install the machine or customer can send technician to our factory for training.
Buyer need to pay air thicket & food & hotels.
Remark:
(a) All specifications and designs are subject to change without notice.
(b) The price of the machine all are in US dollars based on FOB Shanghai.
(c) The price is base on 380V, 50Hz, 3 Phase, for special power, add additional 5% of all machine.
|
| |
| PS-200/840M |
| ITEMS | A | B | C |
|
| Screw Diameter | mm | 45 | 50 | 55 |
| INECTION UNIT |
| Screw L/D Ratio | L/D | 22.2 | 20 | 18.2 |
|
| Shot Size(Theoretical) | cm3 | 358 | 442 | 535 |
| (Ps) | Injection Weight | g | 326 | 402 | 486 |
|
| Injection Pressure | MPa | 235.3 | 190.6 | 157.5 |
|
| Injection Rate into Air | cm3/s | 141.3 | 176.7 | 174.5 | 218.1 | 211.1 | 263.9 |
|
| Injection Stroke | mm | 225 |
|
| Injection Speed | mm/s | 88/110 |
| (ACC) | Injection Speed(ACC) | mm/s | 304 |
|
| Screw Speed | rpm | 192/240 |
|
| Clamping Force | KN | 2000 |
| CLAMPING UNIT |
| Clamping Stroke | mm | 540 |
|
| Space Between Tie Bar | mm | 530*530 |
|
| Max. Mold Height | mm | 560 |
|
| Min. Mold Height | mm | 220 |
|
| Eject Stroke | mm | 150 |
|
| Eject Force | KN | 67 |
|
| No. Of Ejector Pins | piece | 9 |
| |
| Max. Pump Pressure | MPa | 17.5 |
| OTHERS |
| Pump Motor Power | KW | 20/25 |
|
| Heater Power | KW | 15.9 |
|
| Hopper Capacity | Kg | 50 |
|
| Oil Tank Capacity | L | 400 |
|
| Weight | t | 6.5 |
WUXI POSHSTAR INDUSTRY Co., Ltd. is established in 2003, succeeding blow moulding techniques & experiences accumulated many years by our engineers and technicians in this field.
We have been able to carve a niche in the industry due to the unstinting support of our industrious team; In other words, our team is the backbone of our organization. Our professionals possess vast experience, expertise and extensive knowledge in their respective domain which allows them to utilize their skill and talent wisely. We also can provide all the necessary facilities to our workforce in order make the latest and most advanced technology available to them. We have appointed the following professionals as a part of our team:
(1)Designers
(2)Quality Analysts
(3)Skilled Craftsmen
(4)Machine Operators
(5)Packaging Experts
(6)Sales and Marketing Professionals
Looking forward to cooperating with you in future.
Contact Person: Peter
Tel: 0086-510-82820051
Mobile: 0086-13812175742
Fax: 0086-510-82822112
Add: Times International C, Nanchang Area, Wuxi city, Jiangsu province, China.
