Wenzhou WOSN Electron Technology Co., Ltd. >> 300W Single Output Switching Power Supply 24V

300W Single Output Switching Power Supply 24V

Name: 300W Single Output Switching Power Supply 24V
Brand: china-manufacturer-directory.com
SKU: 731173295
Availability: InStock
Rating: 4.7 (123 reviews)

Supplier:	Wenzhou WOSN Electron Technology Co., Ltd.
Price:	US $ 1-100Piece
Min Order:	10Pieces
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	S-300-24
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Voltage:	24V
Output Frequency:	47~63Hz
Output Current:	0-12.5A
Color:	Metal
Power Supply Type:	Compact Single
Protection:	Short Circuit/Over Load/Over Voltage
OEM:	Accept
Keywords:	Switching Power Supply
Efficiency:	85%
Port:	Ningbo Port
Output Type:	Single
Output Power:	201 - 300W
Voltage Regulating Mode:	Frequency Modulation Type
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Warranty:	2 Years
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	ISO
Input Voltage:	85~132VAC/170~264VAC Selected by Switch 47~63Hz,24

Product Description

Product Description

-AC input voltage range selected by switch
-Small volume, low weight, high efficiency
-Protections: Short circuit/over load/over voltage/over temp
-Built-in cooling DC fan
-Cooling fan ON-OFF auto control
-LED indicator for power on
-100% full load burn-in test
-2 Years warranty

Company Introduction

Wenzhou Wosn Electron Technology Co., Ltd. Is a manufacturer specialized in developing, producing and marketing voltage regulators. Since the foundation of our company, we have been persisting in taking science and technology as forerunner and abundant technology as backing, and actively introducing overseas advanced technology to unceasingly improve product quality.

With many years' specialized management, our products are now best-selling in China and are also exported to Bangladesh, Indonesia, Thailand and other countries in Southeast Asia and Africa. Some of them are well sold to all over the world meanwhile receiving high praise from the majority of customers.

Model Specification	S-300-5	S-300 -12	S-300 -24	S-300 -48
DC output	5V 60A	12V 25A	24V 12.5A	48V 6A
Wave and noise	100mVp-p	120mVp-p	120mVp-p	150mVp-p
Inlet stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±0.5%	±0.5%	±0.5%	±0.5%
Efficiency	76%	83%	85%	86%
Adjustable range for DC voltage	±10%	±10%	±10%	±10%
AC input voltage range	85~132VAC/170~264VAC Selected by switch 47~63Hz,240~370VDC
AC input voltage range	Cold-start current 18A/115V 36A/230V
OverLoad protection	105%~135% hiccup mode,auto-recovery
OverLoad protection
Setup,rise,hold up time	200ms 50ms 20ms
Withstand voltage	I/P-O/P:1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv 1minute
Isolation resistance	I/P-O/P, I/P-FG, O/P-FG:500VDC/100MΩ
Working temperature	-10°C~+50°C
Safety standards	Design refer to GB4943,UL60950,EN60950
EMC standards	Design refer to GB9254,EN55022 classB
Weight	2.19 kg
