Nema 17 stepping motor, 42mm linear stepper motor
Model: 42HB34F04AGF01 200 steps per revolution (1.8 deg/step)
2 Phase
Rated Voltage 2.52v
Rated Current (peak value when microstep 0.4A
Coil Resistance/phase: 1.5 Ohm ± 10% (20º C)
Coil Inductance/phase: 2.3mH ± 20% (1kHz 1 V rms)
Holding torque: 2.6KG. CM
Shaft diameter: 5mm / 0.188" (3/16")
Shaft length: 210 mm with 5mm unthreaded cap
Motor depth: 34mm
Lead Screw Tr8x8(P2)
|
Model No. |
Voltage(V) |
Current(A) |
Resistance(Ω) |
Inductance(mH) |
Lead Wire No. |
Motor Length(mm) |
|
BH42HBS1735-01 |
7.2 |
0.5 |
14.4 |
19.8 |
4 |
35 |
|
BH42HBS1735-02 |
3.6 |
1.0 |
3.6 |
5.0 |
4 |
35 |
|
BH42HBS1735-03 |
2.4 |
1.5 |
1.6 |
2.2 |
4 |
35 |
|
BH42HBS1749-01 |
11.0 |
0.5 |
22 |
46 |
4 |
49 |
|
BH42HBS1749-02 |
4.5 |
1.2 |
3.8 |
8.0 |
4 |
49 |
|
BH42HBS1749-03 |
2.2 |
2.5 |
0.87 |
1.8 |
4 |
49 |
Changzhou Bo Hong Electric Appliance Co., Ltd is specialized in R&D, production and sales of stepping motors, Brushless motors, AC servo motors and drive systems. With complete testing equipment, advanced testing methods and strict standards, we devote ourselves to improving the quality and performance of our products and to provide high quality products as per international standards for global engineering-control industry with excellent and quick technical support as well as aftersales service.
The company products are mainly exported to the United States, Italy, Germany and other European developed country, all products are in line with the CE and RoHS standards, won praise at home and abroad!
The company owns a group of excellent and experienced management & Technical stuff. We insists the principle: "Reliable Quality, thoughtful & honest service, systemized & efficient management, innovative technology, improved system, enhance customers' Satisfaction". After many year' S development, we settled many technical difficult for home and abroad customers by our excellent product quality and technical solution. The products mainly applied in industries of robots, medical equipment, office automation, electronics, printing equipment, textile machinery, monitoring system, computer, advertising equipment, stage lighting, the NC machine etc.
