Product Specifications
| Prod Model: |
MS8360F |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Grade: |
Professional |
| LCD Display: |
4000 Counts |
| Diode: |
2.7V |
| Display Mode: |
Digital |
| Power Source: |
AC and DC |
| Theory: |
Electronic Meter |
| Installation: |
Portable |
Product Description
Digital Multimeter MS8360F
Features of Digital Multimeter MS8360F
* Display: 4000 counts
* Auto Ranging: Auto and Manual range
* REL: Relative measurement
* NCV: Non-contact voltage detector
* Transistor hFE: 0~1000
* Didoe: 2.7V
* Continuity Buzzer: <50Ω
* Data hold: yes
* Display backlight: yes
Specifications of Digital Multimeter MS8360F
* DC Voltage
- Range: 400mV/4V/40V/400V/600V; Accuracy: +/-(0.5%+2)
* AC Voltage
- Range: 400mV/4V/40V/400V/600V; Accuracy:+/-(0.8%+3)
* DC Current
- Range: 400μA/4000μA/40mA/400mA; Accuracy:+/-(0.8%+2)
- Range: 10A; Accuracy: +/-(1.2%+2)
* AC Current
- Range: 400μA/4000μA/40mA/400mA; Accuracy:+/-(1.5%+2)
- Range: 10A; Accuracy: +/-(2.0%+2)
* Resistance
- Range: 400Ω/4KΩ/40KΩ/400KΩ/4MΩ; Accuracy:+/-(0.8%+1)
- Range: 40MΩ; Accuracy: +/-(1.0%+2)
* Capacitance
- Range: 4nF/40nF/400nF/4μF/40μF/200μF; Accuracy: +/-(3%+5)
* Frequency
- Range: 0~10kHz; Accuracy: +/-(0.5%+2)
* Duty cycle
- Range: 1%~99%; Accuracy: +/-(2%+2)
* Power supply: 1x9V 6F22 battery
* Product size: 188mm x 92mm x 50mm /7.4" x 3.6" x 2.0"
* Product weight: 380g/0.83lb
* Safety rating: CE ETL CAT III 600V RoHS
