Product Specifications
| Prod Model: |
MS8340A |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Grade: |
Professional |
| LCD Display: |
4000 Counts |
| Diode: |
2.7V |
| Display Mode: |
Digital |
| Power Source: |
AC and DC |
| Theory: |
Electronic Meter |
| Installation: |
Portable |
Product Description
Autoranging Digital Multimeter MS8340A with 6600 counts
Features of Digital Multimeter MS8340A
* Display: 6000 counts
* Auto Ranging: Auto and manual
* REL: Relative measurement
* LPF: 1KHz Low Pass Filter
* Didoe: 2.7V
* Continuity Buzzer: <50Ω
* Max/Min: yes
* Data hold: yes
* APO: auto power off
* LBD: low battery display
* Display backlight: yes
Specifications of Digital Multimeter MS8340A
* DC Voltage
- Range: 600mV/6V/60V/600V/1000V; Accuracy: +/-(0.8%+3)
* AC Voltage
- Range: 6V/60V/750V; Accuracy:+/-(1%+4)
* DC Current
- Range: 600μA/6mA/60mA/600mA/10A; Accuracy:+/-(1.2%+4)
* AC Current
- Range: 600μA/6mA/60mA/600mA/10A; Accuracy:+/-(1.5%+3)
* Resistance
- Range: 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ; Accuracy:+/-(1%+2)
* Capacitance
- Range: 40nF/400nF/4μF/40μF/400μF; Accuracy: +/-(3%+2)
* Frequency
- Range: 0~10MHz; Accuracy: +/-(0.2%+3)
* Duty cycle
- Range: 5%~95%; Accuracy: +/-1%
* Temperature
- Range: -10°C~700°C; Accuracy: +/-(2%+2)
- Range: 14°F~1292°F; Accuracy: +/-(2%+4)
* Power supply: 4x1.5V AA batteries
* Product size: 205mm x 102mm x 58mm /8.1" x 4.0" x 2.2"
* Product weight: 470g/1.03lb
* Safety rating: CE GS CAT. III 1000V
