7015AC/C Dbl P4 Angular Contact Ball Bearing (75X115X20mm) High Speed Motor Bearing

Product Specifications

Prod Model:	7015AC DB
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Precision Grade:	P4/P2
Band:	Tmp
Rolling Body:	Ball Bearings
The Number Of Rows:	Single
Outer Dimension:	Small and Medium-Sized (',60-115mm)
Material:	Bearing Steel
Separated:	Unseparated
Spherical:	Angular Contact Ball Bearing
Load Direction:	Radial and Trust Bearing

Product Description

7015AC/C DBL P4 Angular Contact Ball Bearing (75x115x20mm)  high speed  Motor Bearing
A . Angular Contact Ball Bearing Parameters
Brand-	TMP
Structure-	Angular Contact ball
Model number-	7015 AC/C
Inner ring(mm)-	75
Outer ring(mm)-	115
Width(mm)-	20
Weight(Kg)-	0.617
Materials-	Chrome steel/GCR15
Precision grade-	P4/P2
Lubrication type-	Grease lubrication
Contact Angle-	C=15°;AC=25°
Material(Ball)-	Steel ball(SUJ2); SN24:Ceramic ball(Si3N4)
Number of Row-	Single rows
Material(Cage)-	TYN-PA;TR-PF
Combination-	SU:Universal combination (single row) DU:Universal combination (double rows) DB: Back-to-back combination DF: Face-to-face combination DT: Parallel combination DBD.DFD.DTD:  Three rows DBB.DFF.DBT.DFT.DTT: Four rows
Preloaded-	EL: Micro preloaded L : Light preload M : Medium preloade H : Heavy preloaded
B . 7015 Angular Contact Ball Bearing Specification Sheet

Model Number	Dimensions			α=15°		α=25°		Material (Cage )	Weight (kg) Approx
				Limiting speed		Limiting speed
	d	D	B	Basic load  rating	Lubrication	Basic load rating	Lubrication
				Cr Cor	Grease Oil	Cr Cor	Grease Oil
7015	75	115	20	51.3 59.2	10000 17000	48.5 56.2	8500 15000	PA/PF	0.617

C . 70 series Angular Contact Ball Bearing Details

Product Features
Precision Angular Contact Ball BearingsDue to their internal design, angular contact ball bearings can withstand high radial-axial loads and reach high speeds. They are asymmetrical for manufacturing reasons and can withstand unidirectional axial loads only. Angular bearings are usually mounted in a group of two or more opposed preloaded units with rigid or elastic spacers. Typically, the inner and outer raceways and balls are made of chrome steel. Where operating conditions are severe, bearings may have ceramic balls creating a hybrid bearing.

Series Introduction
ISO 10 Series - highest load, second lowest speed bearings-70 Series Angular Contact Bearings

Series Model No.
7000AC/C 7001AC/C 7002AC/C 7003AC/C 7004AC/C 7005AC/C 7006AC/C 7007AC/C 7008AC/C 7009AC/C 7010AC/C 7011AC/C 7012AC/C 7013AC/C 7014AC/C 7015AC/C 7016AC/C 7017AC/C 7018AC/C 7019AC/C 7020AC/C 7021AC/C 7022AC/C 7024AC/C 7026AC/C 7028AC/C 7030AC/C 7032AC/C 7034AC/C 7036AC/C 7038AC/C 7040AC/C 7044AC/C 7048AC/C 7052AC/C 7056AC/C 7060AC/C 7064AC/C 7068AC/C 7072AC/C 7076AC/C 7080AC/C 7084AC/C

Applications "Angular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrial equipment."
