Product Specifications
| Prod Model: |
AHC8A |
| Markets: |
North America,South America,Eastern Europe,Africa,Oceania,Western Europe |
| Brand: |
Winston |
| Max. Current: |
16A |
| Max. Voltage: |
220VAC |
| Quality: |
2 Year Warranty |
| Dimensions(mm): |
50X100X66 |
| Contact Form: |
1no, 1nc/1no |
| OEM/ODM: |
Yes |
| Condition: |
Original New |
| Contact Voltage: |
AC220V 50/60Hz 85%~110 |
| Temperaturer: |
: -10 ~ +40 Degree |
| Type: |
Time Switch |
| Usage: |
Industrial |
| Theory: |
Mechanical |
| Mechanism: |
Mechanical |
Product Description
Product Description
1) Time range: Per day or per week cycle
2) Contact capacity: 16A 250V AC
3) Coil voltage: AC230V 50/60HZ
4) Electrical life: 100,000 times
5) Mechanical life: 10,000,000 times
6) Working reserve time: 3years
7) Minimum setting unit: 1 minute
8) Programmable: 8ON/OFF per day or per week cycle
9) Operating temperature: -20 - +50°C
10)Time accuracy: ≤1s/day at +20 °C
Technique parameter
| CLASSIFICATION | WEEKLY PROGRAMMABLE |
| MODEL | AHC8A | AHC8 |
| DIMENSIONS(mm) | 50X100X66 | 48X48X95 |
| FULL TIMING RANGE | Per weel or per day cycle |
| RATED VOLTAGE | AC 220V 50/60HZ 85%~110% |
| CONTACT CAPACITY | 16(10)A, 250V AC |
| CONTACT FORM | 1NO, 1NC/1NO | 1NO |
| ACCURACY | <2S/DAY |
| EXPECTANCY DISPLAY | LCD |
| MOUNTING HOLES | ---- | 45X45mm |
| MOUNTING FORM | Front-panel, DIN RAIL | Front-panel, DIN RAIL |
| LIFE | ELECTRICAL | >10^5 times |
| MECHANICAL | >10^7 times |
| TEMPERATURER | -10ºC~+40ºC |
| PROGRAMMABLE | 8 ON/OFF per day or per week |
| STORAGE BATTERY | 2 Years |
| CONSUMED POWER | 5.5VA |
PS:If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
