Product Specifications
| Prod Model: |
DLQC-FZ015 |
| Markets: |
North America,South America,Southeast Asia,Africa,Mid East,Eastern Asia |
| Training: |
Automotive GPS System Demonstrating Board |
| Basic Configuration: |
Navigation Equipment Assembly |
| Software System: |
Fault Setting and Appraisal System |
| Size: |
1260 * 850 *1860mm. |
| Frame Material: |
GB High Quality (40 * 60 * 3mm) Square Tube Weldin |
| Feature: |
Mobile Device with Locking Casters |
| Type: |
Teaching Model |
Product Description
DLQC-FZ015
Automotive GPS System Demonstrating Board
1. Introduction
The device is designed based on satellite GPS navigation to holistically demonstrate structures and operation of system. All parts are original parts, before delivery through layers of inspection, production quality management according to ISO9001: 2008 standards implementation. The device applies to theoretical teaching and maintenance training of satellite GPS navigation system in secondary and senior vocational skill schools, normal education and training institutions.
2. Basic Configuration
Navigation equipment assembly, speakers, relay and fuse box, training panel, ignition switch, power switch, ignition key, DC12 power, movable framework (with self-retention wheels), supporting manual and training guide book and other components.
.
3. Features
1. Real and operable automobile GPS navigation system are used to illustrate structures and works of system.
2. Automobile GPS navigation can be done accurately positioning, navigation maps, four kinds of route search mode, Chinese and English voice prompts, trip information display, detailed route planning, FM sound transmitter function; .
3. Automotive GPS satellite positioning system fault detection internship
4. The instruction board is installed GPS navigation color circuit diagram with detection terminals to detect electric signals, for example, resistance, voltage, current, and frequency, of circuit components.
5. The teaching board's base frame is made of steel and the surface is paint-coated. Self-retention wheels are installed and a 40cm2 tabletop is fixed on the base frame to place materials and light testing devices.
6. Fault setting and appraisal system (see fault setting and appraisal features).
4. Training content
1. Automobile GPS navigationsystem structure composition and working principle project training.
2. Automobile GPS navigation system function demonstration project training
3. Automobile GPS navigation system each circuit element voltage, resistance, signal detection project training.
4. Automobile GPS navigationsystem circuit diagram analysis project training.
5. Automobile GPS navigationsystem troubleshooting and exclusions training.
5. Technique feature
1. Bracket adoped imported luxury car paint, sprayed at high temperatures, with anti-corrosion function.
2. Support frame material select GB high quality (40 * 60 * 3mm) square tube welding.
3. Dimensions: . 1260 * 850 *1860mm.
