Product Specifications
| Prod Model: |
MS8229N |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Grade: |
Professional |
| LCD Display: |
4000 Counts |
| Diode: |
2.7V |
| Display Mode: |
Digital |
| Power Source: |
AC and DC |
| Theory: |
Electronic Meter |
| Installation: |
Portable |
Product Description
Autoranging Digital Multimeter MS8229N
Features of Digital Multimeter MS8229N
* Display: 4000 counts
* Auto Ranging: yes
* °C/°F selection: yes
* Didoe: 2.7V
* Continuity Buzzer: <50Ω
* Data hold: yes
* LBD: low battery display
* Display backlight: yes
Specifications of Digital Multimeter MS8229N
* DC Voltage
- Range: 400mV/4V/40V/400V/1000V; Accuracy: +/-(0.7%+2)
* AC Voltage
- Range: 400mV/4V/40V/400V/750V; Accuracy: +/-(0.8%+3)
* DC Current
- Range: 400μA/4000μA/40mA/400mA; Accuracy:+/-(1.2%+3)
- Range: 4A/10A; Accuracy: +/-(2.0%+10)
* AC Current
- Range: 400μA/4000μA/40mA/400mA; Accuracy:+/-(1.5%+3)
- Range: 4A/10A; Accuracy: +/-(3.0%+10)
* Resistance
- Range: 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ; Accuracy:+/-(1.2%+5)
* Capacitance
- Range: 40nF/400nF/4μF/40μF/100μF; Accuracy: +/-(3.0%+3)
* Frequency
- Range: 10Hz/100Hz/1kHz/10kHz/100kHz; Accuracy: +/-(2.0%+5)
* Duty cycle
- Range: 0.1%~99.9%; Accuracy: +/-(3.0%)
* Temperature(°C/°F)
- Range: -20°C~1000°C; Accuracy:+/-(2.0%)
- Range: -4°F~1832°F; Accuracy:+/-(2.0%)
* Environment T(°C/°F)
- Range: 0°C~40°C; Accuracy:+/-2.0°C
- Range: 32°F~104°F; Accuracy:+/-4.0°F
* Relative Humidity
- Range: 30%~95%; Accuracy: +/-5.0%
* Sound Level
- Range: 35db~100db; Accuracy: +/-3.5%
* Luminosity
- Range: 4000Lux/40000Lux; Accuracy: +/-5.0%
* Power supply: 3x1.5V AAA batteries
* Product size: 195mm x 92mm x 55mm /7.7" x 3.6" x 2.2"
* Product weight: 390g/0.86lb
* Safety rating: CAT. III 600V CAT.II 1000V ETL
