Product Specifications
| Prod Model: |
MS8040 |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Grade: |
Professional |
| LCD Display: |
4000 Counts |
| Diode: |
2.7V |
| Display Mode: |
Digital |
| Power Source: |
AC and DC |
| Theory: |
Electronic Meter |
| Installation: |
Portable |
Product Description
Autoranging Bench Top Multimeter with 22000 Counts MS8040
Features of Top Multimeter MS8040
* Display: 22000 counts
* Auto Ranging: yes
* Manual Ranging: yes
* Dual display: yes
* Segments Bar Graph: 44
* True RMS: For AC voltage and AC current
* Low pass filter(1kHz): For AC voltage and AC current
* Relative measurement: yes
* Peak measurement: yes
* Didoe: 2.7V
* Continuity Buzzer: <50Ω
* Max/Min: yes
* Data hold: yes
* Display backlight: yes
* USB interface: window OS
Specifications of Top Multimeter MS8040
* DC Voltage
- Range: 200mV/2V/20V/200V/1000V; Accuracy: +/-(0.05%+6)
* AC Voltage
- Range: 50mV/500mV/5V/50V/500V/750V; Accuracy: +/-(0.5%+30)
* DC Current
- Range: 200μA/2mA/20mA/200mA; Accuracy:+/-(0.15%+15)
- Range: 10A; Accuracy: +/-(0.5%+15)
* AC Current
- Range: 200μA/2mA/20mA/200mA; Accuracy:+/-(0.8%+30)
- Range: 10A; Accuracy: +/-(1.0%+30)
* Resistance
- Range: 200Ω/2KΩ/20KΩ/200KΩ/2MΩ; Accuracy:+/-(0.1%+5)
- Range: 20MΩ; Accuracy: +/-(0.5%+10)
- Range: 200MΩ; Accuracy: +/-(2%+10)
* Capacitance
- Range: 20nF/200nF/2μF/20μF; Accuracy: +/-(1.2%+30)
- Range: 200μF/2000μF/20mF/200mF; Accuracy: +/-(2.2%+30)
* Logic Frequency
- Range: 20Hz~220MHz; Accuracy: +/-(0.06%+10)
* Duty cycle
- Range: 5%~95%; Accuracy: +/-10%
* Linear Frequency
- Range: 5Hz~100kHz; Accuracy: +/-(0.06%+10)
* Temperature(°C/°F)
- Range: -30°C~1300°C; Accuracy:+/-(1%+2)
- Range: -22°F~2372°F; Accuracy:+/-(1%+4)
* Clamp DC Current
- Range: 220A/2200A; Accuracy:+/-(0.1%+10)
* Clamp AC Current
- Range: AC(50~60hZ)220A/2200A; Accuracy:+/-(1%+30)
* Power supply: 220V/110V AC(50~60Hz),1x9V 6F22 battery,6x1.5V AA batteries
* Product size: 238mm x 230mm x 83mm /9.4" x 9.1" x 3.3"
* Product weight: 1360g/3.0lb
* Safety rating: CE CAT. II 1000V RoHS
